Commercial
Non-Insulated
Terminals

Filter
10-410-4-088
10-410-4-088
10-410-4-088
0.493" - - Swage Mount 0.165" 1/8 0.116 Brass Bright Tin-Lead NO
09-0295-2-04
09-0295-2-04
09-0295-2-04
0.152" 0.030 - Solder 0.090" 1/64 TO 1/16 0.032 Brass Electro-Tin YES
10-806-6-04
10-806-6-04
10-806-6-04
0.661" - - Swage Mount 0.234" 3/16 0.094 Brass Electro-Tin YES
10-405-2-04
10-405-2-04
10-405-2-04
0.426" - - Swage Mount 0.109" 1/16 0.116 Brass Electro-Tin YES
09-9505-1-04
09-9505-1-04
09-9505-1-04
0.444" 0.045 - 0-80 Screw - 1/32 TO 1/16 CLEARANCE FOR #0 Screw Brass Electro-Tin YES
10-431-4-04
10-431-4-04
10-431-4-04
0.219" - - Swage Mount 0.139" 1/8 0.036 Brass Electro-Tin YES
10-483-2-04
10-483-2-04
10-483-2-04
0.433" - - Swage Mount 0.105" 1/16 0.116 Brass Electro-Tin YES
09-0056-2-04
09-0056-2-04
09-0056-2-04
0.259" - - Swage Mount 0.100" 1/16 0.067 Brass Electro-Tin YES
09-8139-2-04
09-8139-2-04
09-8139-2-04
0.144" 0.020 - Swage Mount 0.084" 1/16 0.037 Brass Electro-Tin YES
09-8003-1-03
09-8003-1-03
09-8003-1-03
0.405" 0.080 - Swage Mount 0.105" 1/16 0.094 Brass Gold YES
10-901-1-04
10-901-1-04
10-901-1-04
0.218" 0.060 - Swage Mount 0.062" 1/32 0.064 Brass Electro-Tin YES
10-502-4-04
10-502-4-04
10-502-4-04
0.413" - TURRET/DOUBLE TURRET Swage Mount 0.145" 1/8 0.076 Brass Electro-Tin YES
10-816-4-04
10-816-4-04
10-816-4-04
0.365" - - Swage Mount 0.165" 1/8 0.1495 Brass Electro-Tin YES
10-459-5-04
10-459-5-04
10-459-5-04
0.334" - - Swage Mount 0.178" 5/32 0.064 Brass Electro-Tin YES
10-321-2-04
10-321-2-04
10-321-2-04
0.468" - Turret/Turret Swage Mount 0.094" 1/16 0.120 Brass Electro-Tin YES
10-468-2-04
10-468-2-04
10-468-2-04
0.344" - - Swage Mount 0.105" 1/16 0.094 Brass Electro-Tin YES
10-901-3-05
10-901-3-05
10-901-3-05
0.281" 0.060 - Swage Mount 0.125" 3/32 0.064 Brass Electro Solder NO
10-467-5-05
10-467-5-05
10-467-5-05
0.883" - - Swage Mount 0.195" 5/32 0.1875 Brass Electro Solder NO
10-863-3-05
10-863-3-05
10-863-3-05
0.438" 0.040 - Swage Mount 0.125" 3/32 0.094 Brass Electro Solder NO
10-862-2-05
10-862-2-05
10-862-2-05
0.344" 0.040 - Swage Mount 0.094" 1/16 0.094 Brass Electro Solder NO
