Commercial
Non-Insulated
Terminals

Filter
09-8171-2-04
09-8171-2-04
09-8171-2-04
0.924" 0.040 - Swage Mount 0.082" 1/16 0.076 Brass Electro-Tin YES
10-894-1-088
10-894-1-088
10-894-1-088
0.316" 0.040 TURRET/PIN Swage Mount 0.051" 1/32 0.076 Brass Bright Tin-Lead NO
10-466-1-03
10-466-1-03
10-466-1-03
0.309" - TURRET/THREAD Swage Mount 0.051" 1/32 0.076 Brass Gold YES
10-418-1-01
10-418-1-01
10-418-1-01
0.606" - Turret/Turret Swage Mount 0.075" 1/32 0.120 Brass Silver YES
10-838-8-05
10-838-8-05
10-838-8-05
0.813" 0.050 Pin/Pin Swage Mount 0.281" 1/4 0.111 Brass Electro Solder NO
10-839-2-088
10-839-2-088
10-839-2-088
0.813" 0.050 Pin/Pin Swage Mount 0.094" 1/16 0.111 Brass Bright Tin-Lead NO
10-521-4-05
10-521-4-05
10-521-4-05
0.618" 0.094 Pin/Pin Swage Mount 0.165" 1/8 0.185 Brass Electro Solder NO
10-521-5-044
10-521-5-044
10-521-5-044
0.648" 0.094 Pin/Pin Swage Mount 0.195" 5/32 0.185 Brass Bright Tin YES
10-921-1-035
10-921-1-035
10-921-1-035
0.270" 0.045 - Swage Mount 0.062" 1/32 0.064 Brass Gold YES
10-922-1-03
10-922-1-03
10-922-1-03
0.302" 0.045 - Swage Mount 0.062" 1/32 0.064 Brass Gold YES
10-513-8-04
10-513-8-04
10-513-8-04
0.760" - TURRET/DOUBLE TURRET Swage Mount 0.290" 1/4 0.129 Brass Electro-Tin YES
14-947-3-04
14-947-3-04
14-947-3-04
0.298" - - Swage Mount 0.125" 3/32 0.063 LEADED Red Brass Electro-Tin YES
14-947-3-095
14-947-3-095
14-947-3-095
0.298" - - Swage Mount 0.125" 3/32 0.063 LEADED Red Brass Hot Solder Dip NO
09-0175-1-088
09-0175-1-088
09-0175-1-088
0.209" - - Swage Mount 0.053" 1/32 0.063 Brass Bright Tin-Lead NO
10-906-4-05
10-906-4-05
10-906-4-05
0.292" - - Swage Mount 0.156" 1/8 0.0635 Brass Electro Solder NO
09-8151-2-04
09-8151-2-04
09-8151-2-04
0.344" 0.038 - Swage Mount 0.094" 1/16 0.0635 Brass Electro-Tin YES
10-906-4-04
10-906-4-04
10-906-4-04
0.292" - - Swage Mount 0.156" 1/8 0.0635 Brass Electro-Tin YES
10-254-2-095
10-254-2-095
10-254-2-095
0.240" - - Swage Mount 0.084" 1/16 0.063 Brass Hot Solder Dip NO
10-464-3-01
10-464-3-01
10-464-3-01
0.185" - - Swage Mount 0.115" 3/32 0.035 Brass Silver YES
10-446-3-035
10-446-3-035
10-446-3-035
0.507" - SLOTTED/DOUBLE TURRET Swage Mount 0.125" 3/32 0.096 Brass Gold YES
