Commercial
Non-Insulated
Terminals

Filter
10-972-1-035
10-972-1-035
10-972-1-035
0.831" 0.040 - Swage Mount 0.061" 1/32 0.043 Brass Gold YES
10-972-1-04
10-972-1-04
10-972-1-04
0.831" 0.040 - Swage Mount 0.061" 1/32 0.043 Brass Electro-Tin YES
10-990-3-05
10-990-3-05
10-990-3-05
0.633" 0.040 - Swage Mount 0.113" 3/32 0.043 Brass Electro Solder NO
09-8037-3-088
09-8037-3-088
09-8037-3-088
0.473" 0.0405 - Swage Mount 0.113" 3/32 0.043 Brass Bright Tin-Lead NO
09-8044-1-03
09-8044-1-03
09-8044-1-03
0.371" 0.031 - Swage Mount 0.051" 1/32 0.043 Brass Gold YES
09-8045-1-05
09-8045-1-05
09-8045-1-05
0.221" 0.031 - Swage Mount 0.051" 1/32 0.043 Brass Electro Solder NO
09-8174-11-04
09-8174-11-04
09-8174-11-04
0.935" 0.025 (+0.000/-0.005) - Swage Mount 0.035" 1/64 0.043 Brass Electro-Tin YES
09-7154-2-03
09-7154-2-03
09-7154-2-03
0.155" 0.023 - RIVET MOUNT 0.036" 1/100 0.035 Brass Gold YES
10-227-3-035
10-227-3-035
10-227-3-035
0.271" - - Swage Mount 0.115" 3/32 0.043 Brass Gold YES
10-216-6-01
10-216-6-01
10-216-6-01
0.467" - - Swage Mount 0.230" 3/16 0.094 Brass Silver YES
19-246-6-05
19-246-6-05
19-246-6-05
0.593" - - Swage Mount 0.234" 3/16 0.116 LEADED Red Brass Electro Solder NO
10-8011-6-01
10-8011-6-01
10-8011-6-01
0.484" - - Swage Mount 0.234" 3/16 0.116 Brass Silver YES
10-714-6-01
10-714-6-01
10-714-6-01
0.792" - DOUBLE TURRET/THREAD Swage Mount 0.230" 3/16 0.204 Brass Silver YES
10-461-2-01
10-461-2-01
10-461-2-01
0.396" - - Swage Mount 0.084" 1/16 0.043 Brass Silver YES
10-121-1-01
10-121-1-01
10-121-1-01
0.176" - - Swage Mount 0.051" 1/32 0.052 Brass Silver YES
09-8642-2-01
09-8642-2-01
09-8642-2-01
0.202" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Silver YES
09-0215-2-05
09-0215-2-05
09-0215-2-05
0.400" 0.030 Pin/Pin Solder 0.090" 1/16 0.136 Brass Electro Solder NO
10-918-3-05
10-918-3-05
10-918-3-05
0.433" 0.040 - Swage Mount 0.113" 3/32 0.043 Brass Electro Solder NO
09-8113-2-05
09-8113-2-05
09-8113-2-05
0.202" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Electro Solder NO
09-0120-4-05
09-0120-4-05
09-0120-4-05
0.331" - - Swage Mount 0.145" 1/8 0.076 Brass Electro Solder NO
