Commercial
Non-Insulated
Terminals

Filter
10-419-2-05
10-419-2-05
10-419-2-05
0.496" - SLOTTED/DOUBLE TURRET Swage Mount 0.105" 1/16 0.094 Brass Electro Solder NO
10-508-2-04
10-508-2-04
10-508-2-04
0.538" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.206 Brass Electro-Tin YES
10-604-2-03
10-604-2-03
10-604-2-03
0.796" - - Swage Mount 0.109" 1/16 0.266 Brass Gold YES
10-809-3-04
10-809-3-04
10-809-3-04
0.258" - - Swage Mount 0.141" 3/32 0.116 Brass Electro-Tin YES
10-821-2-088
10-821-2-088
10-821-2-088
0.438" 0.040 Pin/Pin Swage Mount 0.105" 1/16 0.094 Brass Bright Tin-Lead NO
09-8168-3-04
09-8168-3-04
09-8168-3-04
0.690" 0.090 - Swage Mount 0.135" 3/32 0.094 Brass Electro-Tin YES
10-312-3-04
10-312-3-04
10-312-3-04
0.463" - - Swage Mount 0.135" 3/32 0.082 Brass Electro-Tin YES
10-914-1-01
10-914-1-01
10-914-1-01
0.250" - - Swage Mount 0.062" 1/32 0.0635 Brass Silver YES
09-0357-4-01
09-0357-4-01
09-0357-4-01
0.210" - - 2-56 - - 2-56 THREAD Brass Silver YES
10-416-11-088
10-416-11-088
10-416-11-088
0.193" - - Swage Mount 0.037" 1/64 0.064 Brass Bright Tin-Lead NO
09-8642-1-088
09-8642-1-088
09-8642-1-088
0.171" 0.040 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin-Lead NO
10-8021-3-088
10-8021-3-088
10-8021-3-088
0.433" 0.040 - Swage Mount 0.113" 3/32 0.043 Brass Bright Tin-Lead NO
10-975-2-04
10-975-2-04
10-975-2-04
1.102" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Electro-Tin YES
10-240-2-04
10-240-2-04
10-240-2-04
0.469" - - Swage Mount 0.105" 1/16 0.116 Brass Electro-Tin YES
10-875-2-035
10-875-2-035
10-875-2-035
0.182" 0.025 - Swage Mount 0.082" 1/16 0.052 Brass Gold YES
09-0183-1-035
09-0183-1-035
09-0183-1-035
0.203" 0.030 - Swage Mount 0.078" 1/16 0.062 Brass Gold YES
10-221-1-035
10-221-1-035
10-221-1-035
0.266" - - Swage Mount 0.053" 1/32 0.076 Brass Gold YES
10-467-4-03
10-467-4-03
10-467-4-03
0.853" - - Swage Mount 0.165" 1/8 0.1875 Brass Gold YES
10-550-6-01
10-550-6-01
10-550-6-01
0.699" - TURRET/DOUBLE TURRET Swage Mount 0.230" 3/16 0.206 Brass Silver YES
09-0152-2-04
09-0152-2-04
09-0152-2-04
0.360" - - Swage Mount 0.090" 1/16 0.055 Brass Electro-Tin YES
