Commercial
Non-Insulated
Terminals

Filter
10-838-4-05
10-838-4-05
10-838-4-05
0.688" 0.050 Pin/Pin Swage Mount 0.156" 1/8 0.111 Brass Electro Solder NO
10-837-3-035
10-837-3-035
10-837-3-035
0.469" 0.050 Pin/Pin Swage Mount 0.125" 3/32 0.111 Brass Gold YES
10-823-4-035
10-823-4-035
10-823-4-035
0.628" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.151" 1/8 0.120 Brass Gold YES
10-247-8-095
10-247-8-095
10-247-8-095
0.656" - - Swage Mount 0.297" 1/4 0.116 Brass Hot Solder Dip NO
10-247-8-088
10-247-8-088
10-247-8-088
0.656" - - Swage Mount 0.297" 1/4 0.116 Brass Bright Tin-Lead NO
10-465-4-01
10-465-4-01
10-465-4-01
0.547" - - Swage Mount 0.172" 1/8 0.1405 Brass Silver YES
10-426-1-088
10-426-1-088
10-426-1-088
0.294" - - Swage Mount 0.075" 1/32 0.094 Brass Bright Tin-Lead NO
10-602-3-044
10-602-3-044
10-602-3-044
0.625" - - Swage Mount 0.141" 3/32 0.116 Brass Bright Tin YES
10-562-5-095
10-562-5-095
10-562-5-095
0.663" - Double Turret/Double Turret Swage Mount 0.195" 5/32 0.159 Brass Hot Solder Dip NO
10-562-3-04
10-562-3-04
10-562-3-04
0.603" - Double Turret/Double Turret Swage Mount 0.135" 3/32 0.159 Brass Electro-Tin YES
10-559-3-088
10-559-3-088
10-559-3-088
0.410" - TURRET/DOUBLE TURRET Swage Mount 0.115" 3/32 0.076 Brass Bright Tin-Lead NO
10-550-4-01
10-550-4-01
10-550-4-01
0.634" - TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.206 Brass Silver YES
10-526-2-088
10-526-2-088
10-526-2-088
0.625" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.206 Brass Bright Tin-Lead NO
09-8598-3A-044
09-8598-3A-044
09-8598-3A-044
0.182" - - Swage Mount 0.122" 3/32 0.035 Brass Bright Tin YES
10-515-6-03
10-515-6-03
10-515-6-03
0.996" 0.094 TURRET/PIN Swage Mount 0.230" 3/16 0.185 Brass Gold YES
09-8180-2-01
09-8180-2-01
09-8180-2-01
0.435" 0.020 - Swage Mount 0.085" 1/16 0.039 Brass Silver YES
10-513-4-01
10-513-4-01
10-513-4-01
0.484" - TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.129 Brass Silver YES
10-906-4-044
10-906-4-044
10-906-4-044
0.292" - - Swage Mount 0.156" 1/8 0.0635 Brass Bright Tin YES
10-882-5-044
10-882-5-044
10-882-5-044
0.655" - Turret/Turret Swage Mount 0.195" 5/32 0.147 Brass Bright Tin YES
09-0176-1-044
09-0176-1-044
09-0176-1-044
0.112" - - Swage Mount 0.051" 1/32 0.052 Brass Bright Tin YES
