Commercial
Non-Insulated
Terminals

Filter
10-216-2-044
10-216-2-044
10-216-2-044
0.342" - - Swage Mount 0.105" 1/16 0.094 Brass Bright Tin YES
09-0320-1-044
09-0320-1-044
09-0320-1-044
0.281" - - Press Fit/Solder 0.195" 3/16 TO 7/32 0.055 Brass Bright Tin YES
10-801-1-095
10-801-1-095
10-801-1-095
0.379" 0.040 TURRET/PIN Swage Mount 0.051" 1/32 0.076 Brass Hot Solder Dip NO
10-615-4-095
10-615-4-095
10-615-4-095
0.505" - - Swage Mount 0.165" 1/8 0.090 Brass Hot Solder Dip NO
10-821-4-088
10-821-4-088
10-821-4-088
0.498" 0.040 Pin/Pin Swage Mount 0.165" 1/8 0.094 Brass Bright Tin-Lead NO
10-544-1-088
10-544-1-088
10-544-1-088
0.303" - Turret/Turret Swage Mount 0.062" 1/32 0.094 Brass Bright Tin-Lead NO
10-808-6-035
10-808-6-035
10-808-6-035
0.705" - - Swage Mount 0.234" 3/16 0.094 Brass Gold YES
10-562-5-088
10-562-5-088
10-562-5-088
0.663" - Double Turret/Double Turret Swage Mount 0.195" 5/32 0.159 Brass Bright Tin-Lead NO
10-512-2-05
10-512-2-05
10-512-2-05
0.476" - Double Turret/Double Turret Swage Mount 0.105" 1/16 0.129 Brass Electro Solder NO
10-247-4-035
10-247-4-035
10-247-4-035
0.531" - - Swage Mount 0.172" 1/8 0.116 Brass Gold YES
10-850-4-044
10-850-4-044
10-850-4-044
0.483" 0.040 - Swage Mount 0.153" 1/8 0.094 Brass Bright Tin YES
10-550-3-035
10-550-3-035
10-550-3-035
0.604" - TURRET/DOUBLE TURRET Swage Mount 0.135" 3/32 0.206 Brass Gold YES
10-532-3-044
10-532-3-044
10-532-3-044
0.603" - Double Turret/Double Turret Swage Mount 0.135" 3/32 0.159 Brass Bright Tin YES
10-833-3-044
10-833-3-044
10-833-3-044
0.438" 0.050 - Swage Mount 0.125" 3/32 0.064 Brass Bright Tin YES
10-906-4-088
10-906-4-088
10-906-4-088
0.292" - - Swage Mount 0.156" 1/8 0.0635 Brass Bright Tin-Lead NO
10-825-4-044
10-825-4-044
10-825-4-044
0.493" - - Swage Mount 0.165" 1/8 0.081 Brass Bright Tin YES
10-833-1-05
10-833-1-05
10-833-1-05
0.376" 0.050 - Swage Mount 0.063" 1/32 0.064 Brass Electro Solder NO
09-8852-1-01
09-8852-1-01
09-8852-1-01
0.900" 0.062 ± 0.0005 - - - - - Brass Silver YES
10-814-6-01
10-814-6-01
10-814-6-01
0.484" - - Swage Mount 0.234" 3/16 0.116 Brass Silver YES
10-963-2-04
10-963-2-04
10-963-2-04
0.344" 0.020 (+0.000/-0.005) - Swage Mount 0.094" 1/16 0.036 Brass Electro-Tin YES
