Commercial
Non-Insulated
Terminals

Filter
10-504-2-044
10-504-2-044
10-504-2-044
0.501" - Double Turret/Double Turret Swage Mount 0.094" 1/16 0.094 Brass Bright Tin YES
09-7158-1-01
09-7158-1-01
09-7158-1-01
0.207" 0.025 - RIVET MOUNT 0.064" 1/32 0.0625 Brass Silver YES
09-0368-4-095
09-0368-4-095
09-0368-4-095
0.422" - - Swage Mount 0.172" 1/8 0.266 Brass Hot Solder Dip NO
10-102-1-088
10-102-1-088
10-102-1-088
0.265" - - Swage Mount 0.078" 1/32 0.082 Brass Bright Tin-Lead NO
09-8083-2-04
09-8083-2-04
09-8083-2-04
0.482" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Electro-Tin YES
10-922-3-04
10-922-3-04
10-922-3-04
0.365" 0.045 - Swage Mount 0.125" 3/32 0.064 Brass Electro-Tin YES
14-351-3-03
14-351-3-03
14-351-3-03
0.460" - - Swage Mount 0.135" 3/32 0.196 LEADED Red Brass Gold YES
10-717-8-01
10-717-8-01
10-717-8-01
0.719" - - 6-32 - - 6-32 THREAD Brass Silver YES
10-886-3-01
10-886-3-01
10-886-3-01
0.395" 0.030 - Swage Mount 0.125" 3/32 0.0635 Brass Silver YES
10-502-4-088
10-502-4-088
10-502-4-088
0.413" - TURRET/DOUBLE TURRET Swage Mount 0.145" 1/8 0.076 Brass Bright Tin-Lead NO
10-505-1-01
10-505-1-01
10-505-1-01
0.385" - TURRET/DOUBLE TURRET Swage Mount 0.062" 1/32 0.094 Brass Silver YES
14-348-3A-04
14-348-3A-04
14-348-3A-04
0.480" - - Swage Mount 0.152" 7/64 0.082 LEADED Red Brass Electro-Tin YES
10-401-6-01
10-401-6-01
10-401-6-01
0.375" - - Swage Mount 0.219" 3/16 0.067 Brass Silver YES
10-901-1-035
10-901-1-035
10-901-1-035
0.218" 0.060 - Swage Mount 0.062" 1/32 0.064 Brass Gold YES
10-882-2-035
10-882-2-035
10-882-2-035
0.565" - Turret/Turret Swage Mount 0.105" 1/16 0.147 Brass Gold YES
09-0036-2-01
09-0036-2-01
09-0036-2-01
0.250" - - Swage Mount 0.094" 1/16 0.067 Brass Silver YES
09-8083-4-03
09-8083-4-03
09-8083-4-03
0.550" 0.0405 - Swage Mount 0.150" 1/8 0.043 Brass Gold YES
09-8064-5-03
09-8064-5-03
09-8064-5-03
0.190" 0.020 (+0.000/-0.001) - Swage Mount 0.051" 1/32 0.033 Brass Gold YES
10-511-3-03
10-511-3-03
10-511-3-03
0.807" - Double Turret/Double Turret Swage Mount 0.135" 3/32 0.116 Brass Gold YES
10-522-5-03
10-522-5-03
10-522-5-03
0.664" - Turret/Turret Swage Mount 0.195" 5/32 0.206 Brass Gold YES
