Commercial
Non-Insulated
Terminals

Filter
10-550-4-03
10-550-4-03
10-550-4-03
0.634" - TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.206 Brass Gold YES
10-309-3-03
10-309-3-03
10-309-3-03
0.452" - - Swage Mount 0.135" 3/32 0.116 Brass Gold YES
09-8422-1-01
09-8422-1-01
09-8422-1-01
0.213" - - Swage Mount 0.062" 1/32 0.067 Brass Silver YES
10-313-2-035
10-313-2-035
10-313-2-035
0.433" - - Swage Mount 0.105" 1/16 0.081 Brass Gold YES
10-513-1-03
10-513-1-03
10-513-1-03
0.394" - TURRET/DOUBLE TURRET Swage Mount 0.075" 1/32 0.129 Brass Gold YES
10-714-1-035
10-714-1-035
10-714-1-035
0.637" - DOUBLE TURRET/THREAD Swage Mount 0.075" 1/32 0.204 Brass Gold YES
10-465-2-03
10-465-2-03
10-465-2-03
0.484" - - Swage Mount 0.109" 1/16 0.1405 Brass Gold YES
10-238-2-035
10-238-2-035
10-238-2-035
0.530" - - Swage Mount 0.109" 1/16 0.116 Brass Gold YES
10-702-12-03
10-702-12-03
10-702-12-03
0.732" - - 4-40 - - 4-40 THREAD Brass Gold YES
09-8051-2-03
09-8051-2-03
09-8051-2-03
0.329" 0.025 Pin/Pin Swage Mount 0.084" 1/16 0.076 Brass Gold YES
09-0218-1-03
09-0218-1-03
09-0218-1-03
0.520" 0.025 PIN/TERMINAL Solder 0.030" 1/64 TO 1/32 0.0635 Brass Gold YES
09-8849-1-035
09-8849-1-035
09-8849-1-035
0.815" 0.042 - Solder - - 0.044 Brass Gold YES
14-348-3-04
14-348-3-04
14-348-3-04
0.463" - - Swage Mount 0.135" 3/32 0.082 LEADED Red Brass Electro-Tin YES
10-408-1-04
10-408-1-04
10-408-1-04
0.387" - - Swage Mount 0.075" 1/32 0.116 Brass Electro-Tin YES
09-8689-3-035
09-8689-3-035
09-8689-3-035
0.204" 0.020 - Swage Mount 0.094" 1/16 0.043 Brass Gold YES
09-8298-3-035
09-8298-3-035
09-8298-3-035
0.308" 0.040 - Swage Mount 0.135" 3/32 0.076 Brass Gold YES
09-0226-2-04
09-0226-2-04
09-0226-2-04
0.325" - - Swage Mount 0.115" 3/32 0.067 Brass Electro-Tin YES
09-7166-2-04
09-7166-2-04
09-7166-2-04
0.337" 0.040 - RIVET MOUNT 0.103" 1/16 0.076 Brass Electro-Tin YES
10-459-11-04
10-459-11-04
10-459-11-04
0.193" - - Swage Mount 0.037" 1/64 0.064 Brass Electro-Tin YES
09-8169-1-04
09-8169-1-04
09-8169-1-04
0.211" 0.031 - Swage Mount 0.055" 1/32 0.0465 Brass Electro-Tin YES
