Commercial
Non-Insulated
Terminals

Part No	Length	Pin Diameter	Feed Thru Combination	Mounting	Shank Length	Board Thickness	Hole Size	Terminal Material	Terminal Finish	RoHS
10-469-3-035	0.479"	-	-	Swage Mount	0.135"	3/32	0.113	Brass	Gold	YES
10-919-2-035	0.252"	0.040	-	Swage Mount	0.082"	1/16	0.043	Brass	Gold	YES
09-7192-2-04	0.251"	-	-	RIVET MOUNT	0.100"	1/16	0.073	Brass	Electro-Tin	YES
10-101-8-088	0.374"	-	-	Swage Mount	0.270"	1/4	0.076	Brass	Bright Tin-Lead	NO
10-906-1-035	0.198"	-	-	Swage Mount	0.062"	1/32	0.0635	Brass	Gold	YES
10-416-1-05	0.209"	-	-	Swage Mount	0.053"	1/32	0.064	Brass	Electro Solder	NO
09-0276-2-03	0.187"	-	-	Swage Mount	0.094"	1/16	0.067	Brass	Gold	YES
10-895-2-044	0.600"	0.020	-	-	-	-	-	Brass	Bright Tin	YES
09-8083-1-05	0.451"	0.0405	-	Swage Mount	0.051"	1/32	0.043	Brass	Electro Solder	NO
09-8024-1-088	0.371"	0.031	-	Swage Mount	0.051"	1/32	0.035	Brass	Bright Tin-Lead	NO
10-414-8-03	0.426"	-	-	Swage Mount	0.270"	1/4	0.052	Brass	Gold	YES
09-8807-1-088	0.196"	0.025	-	Swage Mount	0.051"	1/32	0.035	Brass	Bright Tin-Lead	NO
10-102-2-04	0.296"	-	-	Swage Mount	0.109"	1/16	0.082	Brass	Electro-Tin	YES
09-8841-1-035	0.300"	0.040	-	-	-	-	-	Brass	Gold	YES
09-8841-1-01	0.300"	0.040	-	-	-	-	-	Brass	Silver	YES
09-0287-2-088	0.325"	0.052	-	-	-	-	-	Brass	Bright Tin-Lead	NO
09-8055-1-03	0.651"	0.0305	-	Swage Mount	0.051"	1/32	0.043	Brass	Gold	YES
09-8689-4-088	0.235"	0.020	-	Swage Mount	0.124"	3/32	0.043	Brass	Bright Tin-Lead	NO
10-103-6-095	0.468"	-	-	Swage Mount	0.234"	3/16	0.116	Brass	Hot Solder Dip	NO
09-7194-3-035	0.330"	-	-	RIVET MOUNT	0.140"	3/32	0.120	Brass	Gold	YES
