Commercial
Non-Insulated
Terminals

Filter
09-7100-2-04
09-7100-2-04
09-7100-2-04
0.325" 0.040 - RIVET MOUNT 0.086" 1/16 0.042 Brass Electro-Tin YES
09-7122-1-04
09-7122-1-04
09-7122-1-04
0.516" 0.025 SQ. - RIVET MOUNT 0.083" 1/16 0.035 Brass Electro-Tin YES
09-7194-3-044
09-7194-3-044
09-7194-3-044
0.330" - - RIVET MOUNT 0.140" 3/32 0.120 Brass Bright Tin YES
09-7105-1B-044
09-7105-1B-044
09-7105-1B-044
0.166" 0.020 - RIVET MOUNT 0.067" 3/64 0.035 Brass Bright Tin YES
09-7197-1-044
09-7197-1-044
09-7197-1-044
0.443" 0.040 - RIVET MOUNT 0.048" 1/64 0.043 Brass Bright Tin YES
09-7191-2-044
09-7191-2-044
09-7191-2-044
0.251" - - RIVET MOUNT 0.100" 1/16 0.073 Brass Bright Tin YES
09-7138-4-044
09-7138-4-044
09-7138-4-044
0.690" 0.040 (+0.000/-0.004) - RIVET MOUNT 0.165" 1/8 0.044 Brass Bright Tin YES
09-7193-2-05
09-7193-2-05
09-7193-2-05
0.494" - - RIVET MOUNT 0.125" 1/16 0.116 Brass Electro Solder NO
09-7119-2-044
09-7119-2-044
09-7119-2-044
0.380" 0.020 - RIVET MOUNT 0.083" 1/16 0.035 Brass Bright Tin YES
09-7181-1-044
09-7181-1-044
09-7181-1-044
0.197" - - RIVET MOUNT 0.052" 1/32 0.036 Brass Bright Tin YES
09-7141-2-05
09-7141-2-05
09-7141-2-05
0.302" - - RIVET MOUNT 0.089" 1/16 0.0465 Brass Electro Solder NO
09-7132-2-05
09-7132-2-05
09-7132-2-05
0.853" 0.0405 - RIVET MOUNT 0.087" 1/16 0.044 Brass Electro Solder NO
09-7172-2-05
09-7172-2-05
09-7172-2-05
0.341" - - RIVET MOUNT 0.089" 1/16 0.035 Brass Electro Solder NO
09-7191-2-05
09-7191-2-05
09-7191-2-05
0.251" - - RIVET MOUNT 0.100" 1/16 0.073 Brass Electro Solder NO
09-7165-2-05
09-7165-2-05
09-7165-2-05
0.594" 0.063 - RIVET MOUNT 0.098" 1/16 0.067 Brass Electro Solder NO
09-7122-1-05
09-7122-1-05
09-7122-1-05
0.516" 0.025 SQ. - RIVET MOUNT 0.083" 1/16 0.035 Brass Electro Solder NO
09-7124-1-05
09-7124-1-05
09-7124-1-05
0.266" 0.030 - RIVET MOUNT 0.052" 1/32 0.035 Brass Electro Solder NO
09-7156-2-044
09-7156-2-044
09-7156-2-044
0.402" 0.053 - RIVET MOUNT 0.095" 1/16 0.0625 Brass Bright Tin YES
09-7195-2-044
09-7195-2-044
09-7195-2-044
0.433" 0.040 - RIVET MOUNT 0.095" 1/16 0.0625 Brass Bright Tin YES
09-7196-2-01
09-7196-2-01
09-7196-2-01
0.281" 0.030 - RIVET MOUNT 0.083" 1/16 0.035 Brass Silver YES
