Commercial
Non-Insulated
Terminals

Filter
10-211-3-044
10-211-3-044
10-211-3-044
0.641" - - Swage Mount 0.141" 3/32 0.266 Brass Bright Tin YES
10-443-2-044
10-443-2-044
10-443-2-044
0.349" - SLOTTED/TURRET Swage Mount 0.094" 1/16 0.125 Brass Bright Tin YES
09-8080-2-044
09-8080-2-044
09-8080-2-044
0.337" 0.018 - Swage Mount 0.082" 1/16 0.052 Brass Bright Tin YES
10-824-3-044
10-824-3-044
10-824-3-044
0.665" 0.053 (TAPER) TURRET/TAPER PIN Swage Mount 0.125" 3/32 0.147 Brass Bright Tin YES
09-8632-2-044
09-8632-2-044
09-8632-2-044
0.825" 0.032 - Swage Mount 0.082" 1/16 0.055 Brass Bright Tin YES
10-808-4-044
10-808-4-044
10-808-4-044
0.643" - - Swage Mount 0.172" 1/8 0.094 Brass Bright Tin YES
10-201-4-04
10-201-4-04
10-201-4-04
0.331" - - Swage Mount 0.145" 1/8 0.076 Brass Electro-Tin YES
10-501-3-04
10-501-3-04
10-501-3-04
0.299" - Turret/Turret Swage Mount 0.113" 3/32 0.076 Brass Electro-Tin YES
10-445-2-04
10-445-2-04
10-445-2-04
0.382" - SLOTTED/TURRET Swage Mount 0.094" 1/16 0.096 Brass Electro-Tin YES
09-0090-2-04
09-0090-2-04
09-0090-2-04
0.457" - Turret/Turret Swage Mount 0.094" 1/16 0.125 Brass Electro-Tin YES
09-8076-1-044
09-8076-1-044
09-8076-1-044
0.751" 0.0405 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin YES
10-824-4-044
10-824-4-044
10-824-4-044
0.696" 0.053 (TAPER) TURRET/TAPER PIN Swage Mount 0.156" 1/8 0.147 Brass Bright Tin YES
09-8405-8-035
09-8405-8-035
09-8405-8-035
0.640" - - Swage Mount 0.297" 1/4 0.096 Brass Gold YES
09-0175-4-04
09-0175-4-04
09-0175-4-04
0.305" - - Swage Mount 0.150" 1/8 0.063 Brass Electro-Tin YES
10-975-2-03
10-975-2-03
10-975-2-03
1.102" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Gold YES
10-483-3-04
10-483-3-04
10-483-3-04
0.463" - - Swage Mount 0.135" 3/32 0.116 Brass Electro-Tin YES
10-111-1-095
10-111-1-095
10-111-1-095
0.256" - - Swage Mount 0.075" 1/32 0.094 Brass Hot Solder Dip NO
09-8301-2-035
09-8301-2-035
09-8301-2-035
0.248" 0.017 - Solder 0.075" 1/64 TO 3/64 0.0225 Brass Gold YES
09-0384-3-01
09-0384-3-01
09-0384-3-01
0.275" - - 2-56 - - 2-56 THREAD Brass Silver YES
10-214-6-035
10-214-6-035
10-214-6-035
0.365" - - Swage Mount 0.209" 3/16 0.067 Brass Gold YES
