Commercial
Non-Insulated
Terminals

Filter
10-8011-1-05
10-8011-1-05
10-8011-1-05
0.359" - - Swage Mount 0.078" 1/32 0.116 Brass Electro Solder NO
10-814-3-044
10-814-3-044
10-814-3-044
0.391" - - Swage Mount 0.141" 3/32 0.116 Brass Bright Tin YES
10-814-6-088
10-814-6-088
10-814-6-088
0.484" - - Swage Mount 0.234" 3/16 0.116 Brass Bright Tin-Lead NO
10-8011-4-05
10-8011-4-05
10-8011-4-05
0.422" - - Swage Mount 0.172" 1/8 0.116 Brass Electro Solder NO
10-8011-1-035
10-8011-1-035
10-8011-1-035
0.359" - - Swage Mount 0.078" 1/32 0.116 Brass Gold YES
10-814-8-088
10-814-8-088
10-814-8-088
0.547" - - Swage Mount 0.297" 1/4 0.116 Brass Bright Tin-Lead NO
10-809-2-044
10-809-2-044
10-809-2-044
0.258" - - Swage Mount 0.109" 1/16 0.116 Brass Bright Tin YES
10-809-3-088
10-809-3-088
10-809-3-088
0.258" - - Swage Mount 0.141" 3/32 0.116 Brass Bright Tin-Lead NO
10-826-4-03
10-826-4-03
10-826-4-03
0.493" - - Swage Mount 0.165" 1/8 0.081 Brass Gold YES
10-544-1-05
10-544-1-05
10-544-1-05
0.303" - Turret/Turret Swage Mount 0.062" 1/32 0.094 Brass Electro Solder NO
10-312-2-03
10-312-2-03
10-312-2-03
0.433" - - Swage Mount 0.105" 1/16 0.082 Brass Gold YES
10-544-4-035
10-544-4-035
10-544-4-035
0.397" - Turret/Turret Swage Mount 0.156" 1/8 0.094 Brass Gold YES
10-543-1-03
10-543-1-03
10-543-1-03
0.507" - Double Turret/Double Turret Swage Mount 0.062" 1/32 0.094 Brass Gold YES
10-807-3-095
10-807-3-095
10-807-3-095
0.484" - - Swage Mount 0.141" 3/32 0.094 Brass Hot Solder Dip NO
10-808-1-01
10-808-1-01
10-808-1-01
0.549" - - Swage Mount 0.078" 1/32 0.094 Brass Silver YES
09-0151-2-095
09-0151-2-095
09-0151-2-095
0.501" - Double Turret/Double Turret Swage Mount 0.094" 1/16 0.094 Brass Hot Solder Dip NO
09-0186-2-01
09-0186-2-01
09-0186-2-01
0.500" 0.018 SLOTTED/PIN Solder 0.080" 1/16 0.052 Brass Silver YES
10-301-1-04
10-301-1-04
10-301-1-04
0.249" - - Swage Mount 0.062" 1/32 0.076 Brass Electro-Tin YES
09-8705-3-088
09-8705-3-088
09-8705-3-088
0.471" - - Swage Mount 0.141" 3/32 0.094 LEADED Red Brass Bright Tin-Lead NO
09-8705-1-044
09-8705-1-044
09-8705-1-044
0.408" - - Swage Mount 0.078" 1/32 0.094 LEADED Red Brass Bright Tin YES
