Commercial
Non-Insulated
Terminals

Filter
10-461-4-035
10-461-4-035
10-461-4-035
0.459" - - Swage Mount 0.147" 1/8 0.043 Brass Gold YES
10-973-2-01
10-973-2-01
10-973-2-01
0.852" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Silver YES
10-477-6-01
10-477-6-01
10-477-6-01
0.374" - - Swage Mount 0.218" 3/16 0.063 Brass Silver YES
09-8298-2-01
09-8298-2-01
09-8298-2-01
0.278" 0.040 - Swage Mount 0.105" 1/16 0.076 Brass Silver YES
09-8637-1-088
09-8637-1-088
09-8637-1-088
0.170" 0.020 - Solder - - 0.022 Beryllium Copper Bright Tin-Lead NO
09-8564-2-044
09-8564-2-044
09-8564-2-044
0.214" 0.030 - Swage Mount 0.098" 1/16 0.067 LEADED Red Brass Bright Tin YES
10-247-4-04
10-247-4-04
10-247-4-04
0.531" - - Swage Mount 0.172" 1/8 0.116 Brass Electro-Tin YES
10-247-1-095
10-247-1-095
10-247-1-095
0.437" - - Swage Mount 0.078" 1/32 0.116 Brass Hot Solder Dip NO
10-885-1-05
10-885-1-05
10-885-1-05
0.395" 0.030 - - - - - Brass Electro Solder NO
10-512-4-01
10-512-4-01
10-512-4-01
0.536" - Double Turret/Double Turret Swage Mount 0.165" 1/8 0.129 Brass Silver YES
09-8138-11-01
09-8138-11-01
09-8138-11-01
0.077" 0.020 - Swage Mount 0.037" 1/64 0.037 Brass Silver YES
10-320-4-05
10-320-4-05
10-320-4-05
0.355" - - Swage Mount 0.165" 1/8 0.094 Brass Electro Solder NO
10-405-1-01
10-405-1-01
10-405-1-01
0.395" - - Swage Mount 0.078" 1/32 0.116 Brass Silver YES
10-329-6-04
10-329-6-04
10-329-6-04
0.562" - - Swage Mount 0.234" 3/16 0.125 Brass Electro-Tin YES
09-8188-2A-01
09-8188-2A-01
09-8188-2A-01
0.150" 0.025 - Swage Mount 0.060" 3/64 0.035 Brass Silver YES
10-521-3-01
10-521-3-01
10-521-3-01
0.588" 0.094 Pin/Pin Swage Mount 0.135" 3/32 0.185 Brass Silver YES
10-8016-2-01
10-8016-2-01
10-8016-2-01
0.612" 0.080 - Swage Mount 0.082" 1/16 0.094 Brass Silver YES
10-301-1-01
10-301-1-01
10-301-1-01
0.249" - - Swage Mount 0.062" 1/32 0.076 Brass Silver YES
10-519-6-01
10-519-6-01
10-519-6-01
1.155" - Double Turret/Double Turret Swage Mount 0.219" 3/16 0.266 Brass Silver YES
10-520-6-01
10-520-6-01
10-520-6-01
1.167" - Double Turret/Double Turret Swage Mount 0.230" 3/16 0.266 Brass Silver YES
