Commercial
Non-Insulated
Terminals

Filter
10-321-2-04
10-321-2-04
10-321-2-04
0.468" - Turret/Turret Swage Mount 0.094" 1/16 0.120 Brass Electro-Tin YES
10-468-2-04
10-468-2-04
10-468-2-04
0.344" - - Swage Mount 0.105" 1/16 0.094 Brass Electro-Tin YES
10-901-3-05
10-901-3-05
10-901-3-05
0.281" 0.060 - Swage Mount 0.125" 3/32 0.064 Brass Electro Solder NO
10-467-5-05
10-467-5-05
10-467-5-05
0.883" - - Swage Mount 0.195" 5/32 0.1875 Brass Electro Solder NO
09-8187-2-05
09-8187-2-05
09-8187-2-05
0.645" 0.020 - Solder 0.100" 1/64 TO 1/16 0.024 Brass Electro Solder NO
10-514-2-05
10-514-2-05
10-514-2-05
0.345" - Turret/Turret Swage Mount 0.105" 1/16 0.129 Brass Electro Solder NO
10-520-5-05
10-520-5-05
10-520-5-05
1.132" - Double Turret/Double Turret Swage Mount 0.195" 5/32 0.266 Brass Electro Solder NO
10-519-8-05
10-519-8-05
10-519-8-05
1.217" - Double Turret/Double Turret Swage Mount 0.281" 1/4 0.266 Brass Electro Solder NO
10-522-6-05
10-522-6-05
10-522-6-05
0.699" - Turret/Turret Swage Mount 0.230" 3/16 0.206 Brass Electro Solder NO
10-513-3-05
10-513-3-05
10-513-3-05
0.454" - TURRET/DOUBLE TURRET Swage Mount 0.135" 3/32 0.129 Brass Electro Solder NO
10-803-8-05
10-803-8-05
10-803-8-05
0.645" 0.040 TURRET/PIN Swage Mount 0.270" 1/4 0.076 Brass Electro Solder NO
09-8730-1-05
09-8730-1-05
09-8730-1-05
0.343" 0.040 TURRET/PIN Press Fit/Solder 0.195" 7/32 TO 9/32 0.052 Brass Electro Solder NO
10-576-4-04
10-576-4-04
10-576-4-04
0.446" - Turret/Turret Swage Mount 0.165" 1/8 0.120 Brass Electro-Tin YES
10-107-4-05
10-107-4-05
10-107-4-05
0.249" - - Swage Mount 0.156" 1/8 0.067 Brass Electro Solder NO
10-812-8-05
10-812-8-05
10-812-8-05
0.781" - Turret/Turret Swage Mount 0.281" 1/4 0.147 Brass Electro Solder NO
09-0166-1-05
09-0166-1-05
09-0166-1-05
0.201" - - Swage Mount 0.045" 1/32 0.067 Brass Electro Solder NO
10-840-4-05
10-840-4-05
10-840-4-05
0.548" - - Swage Mount 0.165" 1/8 0.1495 Brass Electro Solder NO
09-0033-1-05
09-0033-1-05
09-0033-1-05
0.563" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.206 Brass Electro Solder NO
09-8075-2-05
09-8075-2-05
09-8075-2-05
0.282" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Electro Solder NO
09-8144-3-05
09-8144-3-05
09-8144-3-05
0.393" 0.040 - Swage Mount 0.113" 3/32 0.043 Brass Electro Solder NO
