Commercial
Non-Insulated
Terminals

Filter
10-111-3-01
10-111-3-01
10-111-3-01
0.316" - - Swage Mount 0.135" 3/32 0.094 Brass Silver YES
10-111-3-04
10-111-3-04
10-111-3-04
0.316" - - Swage Mount 0.135" 3/32 0.094 Brass Electro-Tin YES
09-9502-2-03
09-9502-2-03
09-9502-2-03
0.356" 0.040 - 0-80 Screw - 1/16 CLEARANCE FOR #0 Screw Brass Gold YES
09-9504-2-035
09-9504-2-035
09-9504-2-035
0.356" 0.045 - 0-80 Screw - 1/16 CLEARANCE FOR #0 Screw Brass Gold YES
10-839-6-035
10-839-6-035
10-839-6-035
0.938" 0.050 Pin/Pin Swage Mount 0.219" 3/16 0.111 Brass Gold YES
10-834-4-035
10-834-4-035
10-834-4-035
0.531" 0.050 - Swage Mount 0.156" 1/8 0.064 Brass Gold YES
10-838-3-035
10-838-3-035
10-838-3-035
0.656" 0.050 Pin/Pin Swage Mount 0.125" 3/32 0.111 Brass Gold YES
10-837-8-04
10-837-8-04
10-837-8-04
0.626" 0.050 Pin/Pin Swage Mount 0.281" 1/4 0.111 Brass Electro-Tin YES
10-837-4-03
10-837-4-03
10-837-4-03
0.501" 0.050 Pin/Pin Swage Mount 0.156" 1/8 0.111 Brass Gold YES
10-837-6-05
10-837-6-05
10-837-6-05
0.563" 0.050 Pin/Pin Swage Mount 0.219" 3/16 0.111 Brass Electro Solder NO
10-837-8-088
10-837-8-088
10-837-8-088
0.626" 0.050 Pin/Pin Swage Mount 0.281" 1/4 0.111 Brass Bright Tin-Lead NO
10-838-4-04
10-838-4-04
10-838-4-04
0.688" 0.050 Pin/Pin Swage Mount 0.156" 1/8 0.111 Brass Electro-Tin YES
10-831-4-088
10-831-4-088
10-831-4-088
0.344" 0.050 - Swage Mount 0.156" 1/8 0.064 Brass Bright Tin-Lead NO
10-831-6-03
10-831-6-03
10-831-6-03
0.407" 0.050 - Swage Mount 0.219" 3/16 0.064 Brass Gold YES
10-831-6-035
10-831-6-035
10-831-6-035
0.407" 0.050 - Swage Mount 0.219" 3/16 0.064 Brass Gold YES
10-831-6-044
10-831-6-044
10-831-6-044
0.407" 0.050 - Swage Mount 0.219" 3/16 0.064 Brass Bright Tin YES
10-832-3-04
10-832-3-04
10-832-3-04
0.375" 0.050 - Swage Mount 0.125" 3/32 0.064 Brass Electro-Tin YES
10-831-8-04
10-831-8-04
10-831-8-04
0.469" 0.050 - Swage Mount 0.281" 1/4 0.064 Brass Electro-Tin YES
10-832-3-044
10-832-3-044
10-832-3-044
0.375" 0.050 - Swage Mount 0.125" 3/32 0.064 Brass Bright Tin YES
10-833-2-01
10-833-2-01
10-833-2-01
0.407" 0.050 - Swage Mount 0.094" 1/16 0.064 Brass Silver YES
