Commercial
Non-Insulated
Terminals

Filter
10-921-3-01
10-921-3-01
10-921-3-01
0.333" 0.045 - Swage Mount 0.125" 3/32 0.064 Brass Silver YES
10-8012-1-03
10-8012-1-03
10-8012-1-03
0.306" 0.040 (+0.000/-0.003) - Solder - - 0.044 Brass Gold YES
09-0263-1-095
09-0263-1-095
09-0263-1-095
0.140" - - Swage Mount 0.125" 3/32 0.043 Brass Hot Solder Dip NO
09-8422-2-04
09-8422-2-04
09-8422-2-04
0.245" - - Swage Mount 0.094" 1/16 0.067 Brass Electro-Tin YES
09-0285-2-03
09-0285-2-03
09-0285-2-03
0.356" - SLOTTED/TURRET Swage Mount 0.078" 1/16 0.076 Brass Gold YES
10-506-3-01
10-506-3-01
10-506-3-01
0.406" - Turret/Turret Swage Mount 0.125" 3/32 0.120 Brass Silver YES
14-350-5-035
14-350-5-035
14-350-5-035
0.716" - - Swage Mount 0.195" 5/32 0.196 LEADED Red Brass Gold YES
10-109-3-03
10-109-3-03
10-109-3-03
0.284" - - Swage Mount 0.125" 3/32 0.094 Brass Gold YES
10-136-1-01
10-136-1-01
10-136-1-01
0.149" - - Swage Mount 0.055" 1/32 0.041 Brass Silver YES
10-309-5-04
10-309-5-04
10-309-5-04
0.512" - - Swage Mount 0.195" 5/32 0.116 Brass Electro-Tin YES
09-7010-2A-095
09-7010-2A-095
09-7010-2A-095
0.360" 0.050 - Swage Mount 0.110" 1/16 0.055 Brass Hot Solder Dip NO
10-802-2-095
10-802-2-095
10-802-2-095
0.302" 0.032 TURRET/PIN Swage Mount 0.084" 1/16 0.067 Brass Hot Solder Dip NO
09-0181-1-095
09-0181-1-095
09-0181-1-095
0.492" - - Swage Mount 0.062" 1/32 0.062 Brass Hot Solder Dip NO
10-802-3-095
10-802-3-095
10-802-3-095
0.333" 0.032 TURRET/PIN Swage Mount 0.115" 3/32 0.067 Brass Hot Solder Dip NO
10-805-8-035
10-805-8-035
10-805-8-035
0.587" - - Swage Mount 0.297" 1/4 0.094 Brass Gold YES
10-433-8-035
10-433-8-035
10-433-8-035
0.985" - - Swage Mount 0.297" 1/4 0.182 Brass Gold YES
09-0384-3-035
09-0384-3-035
09-0384-3-035
0.275" - - 2-56 - - 2-56 THREAD Brass Gold YES
10-216-8-044
10-216-8-044
10-216-8-044
0.530" - - Swage Mount 0.293" 1/4 0.094 Brass Bright Tin YES
10-940-2-01
10-940-2-01
10-940-2-01
0.282" - - Swage Mount 0.094" 1/16 0.0635 Brass Silver YES
10-206-2-01
10-206-2-01
10-206-2-01
0.275" - - Swage Mount 0.084" 1/16 0.076 Brass Silver YES
