Commercial
Non-Insulated
Terminals

Filter
10-888-1-04
10-888-1-04
10-888-1-04
0.315" 0.023 - Swage Mount 0.065" 1/32 0.042 Brass Electro-Tin YES
10-220-4-04
10-220-4-04
10-220-4-04
0.303" - - Swage Mount 0.147" 1/8 0.064 Brass Electro-Tin YES
10-803-4-04
10-803-4-04
10-803-4-04
0.520" 0.040 TURRET/PIN Swage Mount 0.145" 1/8 0.076 Brass Electro-Tin YES
09-8123-2-04
09-8123-2-04
09-8123-2-04
0.410" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Electro-Tin YES
10-509-3-04
10-509-3-04
10-509-3-04
0.782" - Double Turret/Double Turret Swage Mount 0.125" 3/32 0.204 Brass Electro-Tin YES
09-0304-1-04
09-0304-1-04
09-0304-1-04
0.154" - - Swage Mount 0.060" 1/32 0.055 Brass Electro-Tin YES
09-8765-5-035
09-8765-5-035
09-8765-5-035
0.340" 0.022 (+0.000/-0.002) - Solder 0.180" 1/64 TO 5/32 0.024 Brass Gold YES
09-0340-1-035
09-0340-1-035
09-0340-1-035
0.312" 0.040 (+0.000/-0.003) - Solder 0.062" 1/64 TO 1/32 0.041 Brass Gold YES
10-533-1-035
10-533-1-035
10-533-1-035
0.321" - Turret/Turret Swage Mount 0.075" 1/32 0.094 Brass Gold YES
10-543-6-035
10-543-6-035
10-543-6-035
0.664" - Double Turret/Double Turret Swage Mount 0.219" 3/16 0.094 Brass Gold YES
09-0053-2-035
09-0053-2-035
09-0053-2-035
0.269" - - Press Fit/Solder 0.078" 1/16 0.073 Brass Gold YES
09-0316-3-035
09-0316-3-035
09-0316-3-035
0.215" - - Swage Mount 0.120" 3/32 0.047 Brass Gold YES
10-8020-2-035
10-8020-2-035
10-8020-2-035
0.652" 0.025 - Swage Mount 0.082" 1/16 0.035 Brass Gold YES
09-8181-1-035
09-8181-1-035
09-8181-1-035
0.276" 0.020 - Swage Mount 0.051" 1/32 0.035 Brass Gold YES
10-893-3-035
10-893-3-035
10-893-3-035
1.013" 0.0405 - Swage Mount 0.113" 3/32 0.043 Brass Gold YES
10-349-3-035
10-349-3-035
10-349-3-035
0.469" - - Swage Mount 0.141" 3/32 0.116 Brass Gold YES
10-225-1-035
10-225-1-035
10-225-1-035
0.209" - - Swage Mount 0.053" 1/32 0.067 Brass Gold YES
10-605-2-035
10-605-2-035
10-605-2-035
0.445" - - Swage Mount 0.105" 1/16 0.090 Brass Gold YES
10-432-5-03
10-432-5-03
10-432-5-03
0.632" - - Swage Mount 0.195" 5/32 0.161 Brass Gold YES
09-0364-3-03
09-0364-3-03
09-0364-3-03
0.641" - - Swage Mount 0.141" 3/32 0.140 Brass Gold YES
