Commercial
Insulated
Pin Terminals

Filter
1125-83-0114
1125-83-0114
1125-83-0114
0.725" - - Swage Mount 3/32 0.191 Brass Silver Electro-Tin Brass PTFE Yellow NO
1102-64-08814
1102-64-08814
1102-64-08814
0.556" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Yellow NO
1110-64-04414
1110-64-04414
1110-64-04414
0.443" 0.040 Pin/Pin Press Fit 1/16 0.113 Brass Bright Tin - - PTFE Yellow NO
1110-64-0515
1110-64-0515
1110-64-0515
0.443" 0.040 Pin/Pin Press Fit 1/16 0.113 Brass Electro Solder - - PTFE Green NO
1114R-64-0310
1114R-64-0310
1114R-64-0310
0.310" - - Press Fit 3/32 0.122 Brass Gold - - PTFE Black YES
1127-64-0312
1127-64-0312
1127-64-0312
0.391" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Gold ZINC Brass DIALLYL PHTHALATE Red YES
1175-851-0518
1175-851-0518
1175-851-0518
0.521" 0.040 Pin/Pin PRESS LOCK 1/32 0.126 (+0.003/-0.001) Brass Electro Solder - - PTFE Gray NO
1127-64-0518
1127-64-0518
1127-64-0518
0.391" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Gray NO
1127-64-0514
1127-64-0514
1127-64-0514
0.391" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Yellow NO
1110-64-0414
1110-64-0414
1110-64-0414
0.443" 0.040 Pin/Pin Press Fit 1/16 0.113 Brass Electro-Tin - - PTFE Yellow NO
1112R-64-04410
1112R-64-04410
1112R-64-04410
0.200" - - Press Fit 1/32 0.131 Brass Bright Tin - - PTFE Black YES
1127-64-0513
1127-64-0513
1127-64-0513
0.391" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Orange NO
1127-64-0416
1127-64-0416
1127-64-0416
0.391" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Blue YES
1112R-64-04412
1112R-64-04412
1112R-64-04412
0.200" - - Press Fit 1/32 0.131 Brass Bright Tin - - PTFE Red NO
1127-64-0511
1127-64-0511
1127-64-0511
0.391" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Brown NO
1112R-64-04413
1112R-64-04413
1112R-64-04413
0.200" - - Press Fit 1/32 0.131 Brass Bright Tin - - PTFE Orange NO
1114R-64-08816
1114R-64-08816
1114R-64-08816
0.310" - - Press Fit 3/32 0.122 Brass Bright Tin-Lead - - PTFE Blue NO
1110-64-04418
1110-64-04418
1110-64-04418
0.443" 0.040 Pin/Pin Press Fit 1/16 0.113 Brass Bright Tin - - PTFE Gray NO
1112R-64-0119
1112R-64-0119
1112R-64-0119
0.200" - - Press Fit 1/32 0.131 Brass Silver - - PTFE White YES
1112R-64-0110
1112R-64-0110
1112R-64-0110
0.200" - - Press Fit 1/32 0.131 Brass Silver - - PTFE Black YES
