Commercial
Insulated
Pin Terminals

Filter
1100-57-04410
1100-57-04410
1100-57-04410
0.335" 0.040 - Press Fit 1/32 0.136 Brass Bright Tin - - PTFE Black YES
1127-57-08810
1127-57-08810
1127-57-08810
0.579" - - 2-56 Nut 1/16 0.094 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Black NO
1127-57-08815
1127-57-08815
1127-57-08815
0.579" - - 2-56 Nut 1/16 0.094 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Green NO
1177-57-0112
1177-57-0112
1177-57-0112
0.687" 0.050 Pin/Pin PRESS LOCK 1/32 - 1/16 0.136 Brass Silver - - PTFE Red NO
1100-57-0514
1100-57-0514
1100-57-0514
0.335" 0.040 - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Yellow NO
1100-57-0317
1100-57-0317
1100-57-0317
0.335" 0.040 - Press Fit 1/32 0.136 Brass Gold - - PTFE Violet YES
1127-57-08816
1127-57-08816
1127-57-08816
0.579" - - 2-56 Nut 1/16 0.094 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Blue NO
1100-57-0316
1100-57-0316
1100-57-0316
0.335" 0.040 - Press Fit 1/32 0.136 Brass Gold - - PTFE Blue YES
1127-57-08817
1127-57-08817
1127-57-08817
0.579" - - 2-56 Nut 1/16 0.094 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Violet NO
1113-57-08814
1113-57-08814
1113-57-08814
0.407" 0.040 PIN/Solder CUP Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Yellow NO
1102-57-04418
1102-57-04418
1102-57-04418
0.706" - - Press Fit Up to 1/4 0.158 Brass Bright Tin - - PTFE Gray NO
1125-57-0419
1125-57-0419
1125-57-0419
0.975" - - 4-40 Nut Up to 1/4 0.120 Brass Electro-Tin Electro-Tin Brass PTFE White YES
1100-57-08815
1100-57-08815
1100-57-08815
0.335" 0.040 - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Green NO
1102-57-0113
1102-57-0113
1102-57-0113
0.706" - - Press Fit Up to 1/4 0.158 Brass Silver - - PTFE Orange NO
1100-57-08816
1100-57-08816
1100-57-08816
0.335" 0.040 - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Blue NO
1177-57-0510
1177-57-0510
1177-57-0510
0.687" 0.050 Pin/Pin PRESS LOCK 1/32 - 1/16 0.136 Brass Electro Solder - - PTFE Black NO
1102-57-04414
1102-57-04414
1102-57-04414
0.706" - - Press Fit Up to 1/4 0.158 Brass Bright Tin - - PTFE Yellow NO
1113-57-0113
1113-57-0113
1113-57-0113
0.407" 0.040 PIN/Solder CUP Press Fit 1/32 0.136 Brass Silver - - PTFE Orange NO
1102-57-08815
1102-57-08815
1102-57-08815
0.706" - - Press Fit Up to 1/4 0.158 Brass Bright Tin-Lead - - PTFE Green NO
1100-57-08818
1100-57-08818
1100-57-08818
0.335" 0.040 - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Gray NO
