Commercial
Insulated
Pin Terminals

Filter
1175-444-0516
1175-444-0516
1175-444-0516
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Blue NO
1175-444-0514
1175-444-0514
1175-444-0514
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Yellow NO
1175-444-0512
1175-444-0512
1175-444-0512
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Red NO
1175-444-0511
1175-444-0511
1175-444-0511
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Brown NO
1175-444-04413
1175-444-04413
1175-444-04413
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Orange NO
1175-444-0312
1175-444-0312
1175-444-0312
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Gold - - PTFE Red NO
1175-444-04415
1175-444-04415
1175-444-04415
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Green YES
1175-444-04416
1175-444-04416
1175-444-04416
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Blue YES
1175-444-0110
1175-444-0110
1175-444-0110
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Silver - - PTFE Black YES
1175-444-0111
1175-444-0111
1175-444-0111
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Silver - - PTFE Brown NO
1175-444-0112
1175-444-0112
1175-444-0112
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Silver - - PTFE Red NO
1175-444-0115
1175-444-0115
1175-444-0115
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Silver - - PTFE Green YES
1175-444-0118
1175-444-0118
1175-444-0118
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Silver - - PTFE Gray NO
1175-444-0119
1175-444-0119
1175-444-0119
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Silver - - PTFE White YES
1105-10-0417
1105-10-0417
1105-10-0417
0.705" - Double Turret/Double Turret Press Fit Up to 3/16 0.204 Brass Electro-Tin - - PTFE Violet YES
1107-10-0417
1107-10-0417
1107-10-0417
0.515" 0.040 Pin/Pin Press Fit 1/8 0.136 Brass Electro-Tin - - PTFE Violet YES
1111-10-0518
1111-10-0518
1111-10-0518
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Electro Solder - - PTFE Gray NO
1106-10-0515
1106-10-0515
1106-10-0515
0.620" - - Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Green NO
1178R-10-0318
1178R-10-0318
1178R-10-0318
0.470" 0.040 Pin/Slotted PRESS LOCK 1/32 - 3/32 0.086 Brass Gold - - PTFE Gray NO
1178R-10-0317
1178R-10-0317
1178R-10-0317
0.470" 0.040 Pin/Slotted PRESS LOCK 1/32 - 3/32 0.086 Brass Gold - - PTFE Violet YES
