Commercial
Insulated
Pin Terminals

Filter
1175-372-04412
1175-372-04412
1175-372-04412
0.736" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Red NO
1175-372-0319
1175-372-0319
1175-372-0319
0.736" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Gold - - PTFE White YES
1175-372-0411
1175-372-0411
1175-372-0411
0.736" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Brown NO
1175-371-04414
1175-371-04414
1175-371-04414
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Yellow NO
1175-371-04415
1175-371-04415
1175-371-04415
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Green YES
1175-371-04416
1175-371-04416
1175-371-04416
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Blue YES
1175-371-04418
1175-371-04418
1175-371-04418
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Gray NO
1175-371-0514
1175-371-0514
1175-371-0514
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Yellow NO
1175-371-0517
1175-371-0517
1175-371-0517
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Violet NO
1175-371-0411
1175-371-0411
1175-371-0411
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Brown NO
1175-371-0515
1175-371-0515
1175-371-0515
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Green NO
1175-371-0319
1175-371-0319
1175-371-0319
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Gold - - PTFE White YES
1175-371-0316
1175-371-0316
1175-371-0316
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Gold - - PTFE Blue YES
1175-371-0314
1175-371-0314
1175-371-0314
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Gold - - PTFE Yellow NO
1175-371-0312
1175-371-0312
1175-371-0312
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Gold - - PTFE Red NO
1175-371-0310
1175-371-0310
1175-371-0310
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Gold - - PTFE Black YES
1175-371-0110
1175-371-0110
1175-371-0110
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Silver - - PTFE Black YES
1175-371-0112
1175-371-0112
1175-371-0112
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Silver - - PTFE Red NO
1175-371-0113
1175-371-0113
1175-371-0113
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Silver - - PTFE Orange NO
1175-371-0117
1175-371-0117
1175-371-0117
0.705" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Silver - - PTFE Violet YES
