Commercial
Insulated
Pin Terminals

Filter
1126-37-0117
1126-37-0117
1126-37-0117
0.750" - - 6-32 Nut 1/8 0.144 Brass Silver ZINC Brass PTFE Violet YES
1125-37-0116
1125-37-0116
1125-37-0116
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Silver Electro-Tin Brass PTFE Blue YES
1125-37-0113
1125-37-0113
1125-37-0113
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Silver Electro-Tin Brass PTFE Orange NO
1125-37-0112
1125-37-0112
1125-37-0112
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Silver Electro-Tin Brass PTFE Red NO
1126-37-0315
1126-37-0315
1126-37-0315
0.750" - - 6-32 Nut 1/8 0.144 Brass Gold ZINC Brass PTFE Green YES
1127-37-0416
1127-37-0416
1127-37-0416
0.828" - - Swage Mount 3/16 0.147 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Blue YES
1126-37-0412
1126-37-0412
1126-37-0412
0.750" - - 6-32 Nut 1/8 0.144 Brass Electro-Tin ZINC Brass PTFE Red NO
1125-37-04412
1125-37-04412
1125-37-04412
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin Electro-Tin Brass PTFE Red NO
1125-37-04417
1125-37-04417
1125-37-04417
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin Electro-Tin Brass PTFE Violet YES
1125-37-04418
1125-37-04418
1125-37-04418
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin Electro-Tin Brass PTFE Gray NO
1126-37-0413
1126-37-0413
1126-37-0413
0.750" - - 6-32 Nut 1/8 0.144 Brass Electro-Tin ZINC Brass PTFE Orange NO
1126-37-0415
1126-37-0415
1126-37-0415
0.750" - - 6-32 Nut 1/8 0.144 Brass Electro-Tin ZINC Brass PTFE Green YES
1100-37-0510
1100-37-0510
1100-37-0510
0.460" 0.040 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Black NO
1100-37-0511
1100-37-0511
1100-37-0511
0.460" 0.040 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Brown NO
1100-37-0512
1100-37-0512
1100-37-0512
0.460" 0.040 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Red NO
1100-37-0513
1100-37-0513
1100-37-0513
0.460" 0.040 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Orange NO
1100-37-0514
1100-37-0514
1100-37-0514
0.460" 0.040 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Yellow NO
1100-37-0515
1100-37-0515
1100-37-0515
0.460" 0.040 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Green NO
1100-37-0517
1100-37-0517
1100-37-0517
0.460" 0.040 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Violet NO
1111-37-0312
1111-37-0312
1111-37-0312
0.500" 0.053 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Gold - - PTFE Red NO
