Insulated
PC Jacks

Filter
1138-32-03514
1138-32-03514
1138-32-03514
0.080 0.250 " 0.912" Jack/Pin Press Fit 0.205 1/32 - 17/64 Vertical - - PTFE Yellow -
1138-32-03519
1138-32-03519
1138-32-03519
0.080 0.250 " 0.912" Jack/Pin Press Fit 0.205 1/32 - 17/64 Vertical - - PTFE White -
09-9216-1-04418
09-9216-1-04418
09-9216-1-04418
0.060 0.250 " 0.287" - Solder 0.102  1/32 - 3/32 Vertical Brass Bright Tin-Lead PTFE Gray -
09-9216-1-04419
09-9216-1-04419
09-9216-1-04419
0.060 0.250 " 0.287" - Solder 0.102  1/32 - 3/32 Vertical Brass Bright Tin-Lead PTFE White -
09-9221-1-0110
09-9221-1-0110
09-9221-1-0110
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Silver Nylon Black -
09-9221-1-0112
09-9221-1-0112
09-9221-1-0112
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Silver Nylon Red -
09-9221-1-0114
09-9221-1-0114
09-9221-1-0114
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Silver Nylon Yellow -
09-9221-1-0115
09-9221-1-0115
09-9221-1-0115
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Silver Nylon Green -
09-9221-1-0117
09-9221-1-0117
09-9221-1-0117
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Silver Nylon Violet -
09-9221-1-0312
09-9221-1-0312
09-9221-1-0312
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Gold Nylon Red -
09-9221-1-0313
09-9221-1-0313
09-9221-1-0313
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Gold Nylon Orange -
09-9221-1-0316
09-9221-1-0316
09-9221-1-0316
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Gold Nylon Blue -
1138-32-03516
1138-32-03516
1138-32-03516
0.080 0.250 " 0.912" Jack/Pin Press Fit 0.205 1/32 - 17/64 Vertical - - PTFE Blue -
09-9221-1-0317
09-9221-1-0317
09-9221-1-0317
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Gold Nylon Violet -
1138-04-0310
1138-04-0310
1138-04-0310
0.080 0.200 " 0.376" - Swage Mount 0.068 1/16 Vertical - - PTFE Black -
09-9158-1-0417
09-9158-1-0417
09-9158-1-0417
0.040 0.297 " 0.750" Jack/Pin Solder 0.047 1/32 - 21/64 Vertical Brass Electro-Tin PTFE Violet -
09-9221-1-0319
09-9221-1-0319
09-9221-1-0319
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Gold Nylon White -
1128-65-03510
1128-65-03510
1128-65-03510
0.033 0.200 " 0.400" Jack/Pin Press Fit 0.136 1/32 - 5/32 Vertical - - PTFE Black -
1128-17-0318
1128-17-0318
1128-17-0318
0.050 0.195 " 0.287" Jack/Turret Press Fit 0.172 1/32 - 1/4 Vertical - - PTFE Gray -
1128-08-0313
1128-08-0313
1128-08-0313
0.040 0.140 " 0.345" Jack/Turret Press Fit 0.136 1/32 - 1/8 Vertical - - PTFE Orange -
