Insulated
PC Jacks

Filter
1128-57-03518
1128-57-03518
1128-57-03518
0.080 0.250 " 0.487" - Press Fit 0.205 1/32 - 17/64 Vertical - - PTFE Gray -
09-9301-1-0314
09-9301-1-0314
09-9301-1-0314
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 3/32 Horizontal - - Nylon Yellow -
1138-34-0315
1138-34-0315
1138-34-0315
0.080 0.250 " 0.416" - Swage Mount 0.064 3/32 Vertical - - PTFE Green -
09-9216-1-04413
09-9216-1-04413
09-9216-1-04413
0.060 0.250 " 0.287" - Solder 0.102  1/32 - 3/32 Vertical Brass Bright Tin-Lead PTFE Orange -
09-9216-1-04414
09-9216-1-04414
09-9216-1-04414
0.060 0.250 " 0.287" - Solder 0.102  1/32 - 3/32 Vertical Brass Bright Tin-Lead PTFE Yellow -
09-9216-1-04415
09-9216-1-04415
09-9216-1-04415
0.060 0.250 " 0.287" - Solder 0.102  1/32 - 3/32 Vertical Brass Bright Tin-Lead PTFE Green -
1138-32-0316
1138-32-0316
1138-32-0316
0.080 0.250 " 0.912" Jack/Pin Press Fit 0.205 1/32 - 17/64 Vertical - - PTFE Blue -
09-9208-1-04410
09-9208-1-04410
09-9208-1-04410
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Black -
1128-36-03519
1128-36-03519
1128-36-03519
0.040 0.135 " 0.408" Jack/Pin Press Fit 0.136 1/32 - 1/8 Vertical - - PTFE White -
1128-36-03518
1128-36-03518
1128-36-03518
0.040 0.135 " 0.408" Jack/Pin Press Fit 0.136 1/32 - 1/8 Vertical - - PTFE Gray -
1128-07-03517
1128-07-03517
1128-07-03517
0.040 0.078 " 0.203" Jack/Turret Press Fit 0.136 1/32 - 1/16 Vertical - - PTFE Violet -
1128-16-03513
1128-16-03513
1128-16-03513
0.080 0.225 " 0.467" Jack/Turret Press Fit 0.172 1/32 - 1/4 Vertical - - PTFE Orange -
1128-83-0312
1128-83-0312
1128-83-0312
0.040 0.125 " 0.379" Jack/Turret Press Fit 0.136 1/32 - 3/32 Vertical - - PTFE Red -
09-9063-1-0419
09-9063-1-0419
09-9063-1-0419
0.080 0.325 " 0.603" Jack/Pin Solder 0.043 1/32 - 1/8 Vertical Brass Electro-Tin Polyolefin White -
09-9063-1-0415
09-9063-1-0415
09-9063-1-0415
0.080 0.325 " 0.603" Jack/Pin Solder 0.043 1/32 - 1/8 Vertical Brass Electro-Tin Polyolefin Green -
1138-27-03515
1138-27-03515
1138-27-03515
0.062 0.187 " 0.437" Jack/Solder Cup Press Fit 0.158 1/32 - 3/16 Vertical - - PTFE Green -
09-9175-1-0618
09-9175-1-0618
09-9175-1-0618
0.060 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Electro-Tin PTFE Gray -
1138-27-03513
1138-27-03513
1138-27-03513
0.062 0.187 " 0.437" Jack/Solder Cup Press Fit 0.158 1/32 - 3/16 Vertical - - PTFE Orange -
1138-27-03510
1138-27-03510
1138-27-03510
0.062 0.187 " 0.437" Jack/Solder Cup Press Fit 0.158 1/32 - 3/16 Vertical - - PTFE Black -
1138-27-0319
1138-27-0319
1138-27-0319
0.062 0.187 " 0.437" Jack/Solder Cup Press Fit 0.158 1/32 - 3/16 Vertical - - PTFE White -

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
