Insulated
PC Jacks

Filter
1138-29-03511
1138-29-03511
1138-29-03511
0.080 0.187 " 0.437" Jack/Solder Cup Press Fit 0.172 1/32 - 3/16 Vertical - - PTFE Brown -
1138-29-0310
1138-29-0310
1138-29-0310
0.080 0.187 " 0.437" Jack/Solder Cup Press Fit 0.172 1/32 - 3/16 Vertical - - PTFE Black -
1138-28-03519
1138-28-03519
1138-28-03519
0.040 0.250 " 0.531" Jack/Solder Cup Press Fit 0.136 1/32 - 19/64 Vertical - - PTFE White -
1138-29-03512
1138-29-03512
1138-29-03512
0.080 0.187 " 0.437" Jack/Solder Cup Press Fit 0.172 1/32 - 3/16 Vertical - - PTFE Red -
1138-29-03513
1138-29-03513
1138-29-03513
0.080 0.187 " 0.437" Jack/Solder Cup Press Fit 0.172 1/32 - 3/16 Vertical - - PTFE Orange -
1138-29-03515
1138-29-03515
1138-29-03515
0.080 0.187 " 0.437" Jack/Solder Cup Press Fit 0.172 1/32 - 3/16 Vertical - - PTFE Green -
1138-29-03518
1138-29-03518
1138-29-03518
0.080 0.187 " 0.437" Jack/Solder Cup Press Fit 0.172 1/32 - 3/16 Vertical - - PTFE Gray -
09-9221-1-04415
09-9221-1-04415
09-9221-1-04415
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Bright Tin-Lead Nylon Green -
09-9224-1-0314
09-9224-1-0314
09-9224-1-0314
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Yellow -
09-9092-1-03512
09-9092-1-03512
09-9092-1-03512
0.050 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Gold PTFE Red -
09-9224-1-0315
09-9224-1-0315
09-9224-1-0315
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Green -
09-9224-1-03511
09-9224-1-03511
09-9224-1-03511
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Brown M39024/11-04
1138-29-03519
1138-29-03519
1138-29-03519
0.080 0.187 " 0.437" Jack/Solder Cup Press Fit 0.172 1/32 - 3/16 Vertical - - PTFE White -
09-9221-1-04412
09-9221-1-04412
09-9221-1-04412
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Bright Tin-Lead Nylon Red -
09-9175-1-0615
09-9175-1-0615
09-9175-1-0615
0.060 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Electro-Tin PTFE Green -
09-9225-1-03517
09-9225-1-03517
09-9225-1-03517
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Violet M39024/11-50
09-9224-1-03512
09-9224-1-03512
09-9224-1-03512
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Red M39024/11-02
09-9224-1-03514
09-9224-1-03514
09-9224-1-03514
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Yellow M39024/11-08
09-9307-1-03517
09-9307-1-03517
09-9307-1-03517
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 5/64 Horizontal - - Nylon Violet M39024/11-70
1138-03-0319
1138-03-0319
1138-03-0319
0.080 0.250 " 0.441" - Swage Mount 0.114 1/32 Vertical - - PTFE White -
