Panel Jacks / Terminals
Thread Mount

Filter
09-9228-1-03517
09-9228-1-03517
09-9228-1-03517
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Violet MIL-DTL-39024/10
09-9112-1-0313
09-9112-1-0313
09-9112-1-0313
1.172" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Gold - - Nylon   Orange -
09-9243-1-0316
09-9243-1-0316
09-9243-1-0316
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Blue -
09-9074-1-03513
09-9074-1-03513
09-9074-1-03513
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Orange MIL-DTL-39024/10
09-9228-1-03515
09-9228-1-03515
09-9228-1-03515
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Green MIL-DTL-39024/10
09-9228-1-03512
09-9228-1-03512
09-9228-1-03512
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Red MIL-DTL-39024/10
09-9228-1-03513
09-9228-1-03513
09-9228-1-03513
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Orange MIL-DTL-39024/10
09-9111-1-04413
09-9111-1-04413
09-9111-1-04413
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Bright Tin Beryllium Copper Bright Tin Nylon   Orange -
09-9228-1-0316
09-9228-1-0316
09-9228-1-0316
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Blue -
09-9072-1-0318
09-9072-1-0318
09-9072-1-0318
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Gray -
09-9112-1-0319
09-9112-1-0319
09-9112-1-0319
1.172" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Gold - - Nylon   White -
09-9112-1-0318
09-9112-1-0318
09-9112-1-0318
1.172" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Gold - - Nylon   Gray -
09-9112-1-0310
09-9112-1-0310
09-9112-1-0310
1.172" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Gold - - Nylon   Black -
09-9243-1-0311
09-9243-1-0311
09-9243-1-0311
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Brown -
09-9228-1-0312
09-9228-1-0312
09-9228-1-0312
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Red -
09-9228-1-0318
09-9228-1-0318
09-9228-1-0318
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Gray -
09-9072-1-0315
09-9072-1-0315
09-9072-1-0315
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Green -
09-9074-1-0319
09-9074-1-0319
09-9074-1-0319
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   White -
09-9072-1-0319
09-9072-1-0319
09-9072-1-0319
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   White -
09-9112-1-0316
09-9112-1-0316
09-9112-1-0316
1.172" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Gold - - Nylon   Blue -
