Panel Jacks / Terminals
Thread Mount

Filter
09-9150-1-0316
09-9150-1-0316
09-9150-1-0316
0.9375" 0.080 1/4-32 Nut 0.370 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Blue -
09-9151-1-0319
09-9151-1-0319
09-9151-1-0319
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   White -
20-2124-1-04419
20-2124-1-04419
20-2124-1-04419
0.905" 0.060 5/16-32 Nut 0.500 " 0.323 Up to 3/16 Jack/Turret Brass Bright Tin Beryllium Copper Bright Tin Nylon   White -
20-2124-1-04414
20-2124-1-04414
20-2124-1-04414
0.905" 0.060 5/16-32 Nut 0.500 " 0.323 Up to 3/16 Jack/Turret Brass Bright Tin Beryllium Copper Bright Tin Nylon   Yellow -
