Panel Jacks / Terminals
Thread Mount

Filter
09-9150-1-0310
09-9150-1-0310
09-9150-1-0310
0.9375" 0.080 1/4-32 Nut 0.370 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Black -
09-9184-1-03514
09-9184-1-03514
09-9184-1-03514
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Yellow -
09-9151-1-03517
09-9151-1-03517
09-9151-1-03517
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Violet -
09-9151-1-03512
09-9151-1-03512
09-9151-1-03512
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Red -
09-9183-1-0311
09-9183-1-0311
09-9183-1-0311
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Brown -
09-9184-1-04417
09-9184-1-04417
09-9184-1-04417
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Eyelet Brass Bright Tin Beryllium Copper Bright Tin Nylon   Violet -
20-2124-1-04413
20-2124-1-04413
20-2124-1-04413
0.905" 0.060 5/16-32 Nut 0.500 " 0.323 Up to 3/16 Jack/Turret Brass Bright Tin Beryllium Copper Bright Tin Nylon   Orange -
09-9151-1-04413
09-9151-1-04413
09-9151-1-04413
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Bright Tin Beryllium Copper Bright Tin Nylon   Orange -
09-9151-1-04414
09-9151-1-04414
09-9151-1-04414
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Bright Tin Beryllium Copper Bright Tin Nylon   Yellow -
09-9113-1-04413
09-9113-1-04413
09-9113-1-04413
1.109" 0.080 - 0.420 " 0.257 - Jack/Turret Phosphor Bronze Bright Tin - - Nylon   Orange -
09-9113-1-04412
09-9113-1-04412
09-9113-1-04412
1.109" 0.080 - 0.420 " 0.257 - Jack/Turret Phosphor Bronze Bright Tin - - Nylon   Red -
09-9113-1-04419
09-9113-1-04419
09-9113-1-04419
1.109" 0.080 - 0.420 " 0.257 - Jack/Turret Phosphor Bronze Bright Tin - - Nylon   White -
09-9113-1-04418
09-9113-1-04418
09-9113-1-04418
1.109" 0.080 - 0.420 " 0.257 - Jack/Turret Phosphor Bronze Bright Tin - - Nylon   Gray -
09-9184-1-0317
09-9184-1-0317
09-9184-1-0317
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Violet -
09-9183-1-0317
09-9183-1-0317
09-9183-1-0317
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Violet -
09-9151-1-0311
09-9151-1-0311
09-9151-1-0311
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Brown -
09-9151-1-0315
09-9151-1-0315
09-9151-1-0315
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Green -
09-9151-1-0317
09-9151-1-0317
09-9151-1-0317
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Violet -
09-9151-1-0318
09-9151-1-0318
09-9151-1-0318
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Gray -
09-9150-1-0314
09-9150-1-0314
09-9150-1-0314
0.9375" 0.080 1/4-32 Nut 0.370 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Yellow -
