Commercial
Non-Insulated
Terminals

Part No	Length	Pin Diameter	Feed Thru Combination	Mounting	Shank Length	Board Thickness	Hole Size	Terminal Material	Terminal Finish	RoHS
10-414-8-03	0.426"	-	-	Swage Mount	0.270"	1/4	0.052	Brass	Gold	YES
09-8807-1-088	0.196"	0.025	-	Swage Mount	0.051"	1/32	0.035	Brass	Bright Tin-Lead	NO
10-102-2-04	0.296"	-	-	Swage Mount	0.109"	1/16	0.082	Brass	Electro-Tin	YES
09-8841-1-035	0.300"	0.040	-	-	-	-	-	Brass	Gold	YES
09-8841-1-01	0.300"	0.040	-	-	-	-	-	Brass	Silver	YES
09-0287-2-088	0.325"	0.052	-	-	-	-	-	Brass	Bright Tin-Lead	NO
09-8055-1-03	0.651"	0.0305	-	Swage Mount	0.051"	1/32	0.043	Brass	Gold	YES
09-8689-4-088	0.235"	0.020	-	Swage Mount	0.124"	3/32	0.043	Brass	Bright Tin-Lead	NO
10-103-6-095	0.468"	-	-	Swage Mount	0.234"	3/16	0.116	Brass	Hot Solder Dip	NO
09-7194-3-035	0.330"	-	-	RIVET MOUNT	0.140"	3/32	0.120	Brass	Gold	YES
09-7150-2-088	0.359"	0.050	-	RIVET MOUNT	0.104"	1/16	0.048	Brass	Bright Tin-Lead	NO
09-8390-2-044	0.328"	0.025	-	Swage Mount	0.078"	1/16	0.035	Brass	Bright Tin	YES
14-346-4-03	0.360"	-	-	Swage Mount	0.172"	1/8	0.082	LEADED Red Brass	Gold	YES
10-416-1-03	0.209"	-	-	Swage Mount	0.053"	1/32	0.064	Brass	Gold	YES
09-8131-1-04	0.240"	0.032	TURRET/PIN	Swage Mount	0.051"	1/32	0.067	Brass	Electro-Tin	YES
10-454-4-035	0.406"	-	-	Swage Mount	0.156"	1/8	0.067	Brass	Gold	YES
10-919-2-088	0.252"	0.040	-	Swage Mount	0.082"	1/16	0.043	Brass	Bright Tin-Lead	NO
09-8171-2-044	0.924"	0.040	-	Swage Mount	0.082"	1/16	0.076	Brass	Bright Tin	YES
10-522-2-095	0.574"	-	Turret/Turret	Swage Mount	0.105"	1/16	0.206	Brass	Hot Solder Dip	NO
09-8151-2-03	0.344"	0.038	-	Swage Mount	0.094"	1/16	0.0635	Brass	Gold	YES
