Commercial
Non-Insulated
Terminals

Filter
10-313-4-035
10-313-4-035
10-313-4-035
0.493" - - Swage Mount 0.165" 1/8 0.081 Brass Gold YES
10-103-1-03
10-103-1-03
10-103-1-03
0.312" - - Swage Mount 0.078" 1/32 0.116 Brass Gold YES
10-407-4-088
10-407-4-088
10-407-4-088
0.672" - - Swage Mount 0.172" 1/8 0.1405 Brass Bright Tin-Lead NO
10-218-1-088
10-218-1-088
10-218-1-088
0.312" - - Swage Mount 0.075" 1/32 0.094 Brass Bright Tin-Lead NO
10-805-8-088
10-805-8-088
10-805-8-088
0.587" - - Swage Mount 0.297" 1/4 0.094 Brass Bright Tin-Lead NO
10-214-2A-088
10-214-2A-088
10-214-2A-088
0.250" - - Swage Mount 0.096" 1/16 0.067 Brass Bright Tin-Lead NO
09-7010-2-088
09-7010-2-088
09-7010-2-088
0.235" 0.050 - Swage Mount 0.095" 1/16 0.055 Brass Bright Tin-Lead NO
10-419-2-088
10-419-2-088
10-419-2-088
0.496" - SLOTTED/DOUBLE TURRET Swage Mount 0.105" 1/16 0.094 Brass Bright Tin-Lead NO
10-909-1-088
10-909-1-088
10-909-1-088
0.359" - - Press Fit/Solder 0.134" 1/8 0.096 Brass Bright Tin-Lead NO
10-210-1-04
10-210-1-04
10-210-1-04
0.544" - - Swage Mount 0.075" 1/32 0.116 Brass Electro-Tin YES
10-513-2-05
10-513-2-05
10-513-2-05
0.424" - TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.129 Brass Electro Solder NO
09-0067-2A-05
09-0067-2A-05
09-0067-2A-05
0.279" - - Swage Mount 0.093" 1/16 0.076 Brass Electro Solder NO
19-246-6-044
19-246-6-044
19-246-6-044
0.593" - - Swage Mount 0.234" 3/16 0.116 LEADED Red Brass Bright Tin YES
09-0033-3-095
09-0033-3-095
09-0033-3-095
0.625" - TURRET/DOUBLE TURRET Swage Mount 0.156" 1/8 0.206 Brass Hot Solder Dip NO
09-8810-2-04
09-8810-2-04
09-8810-2-04
0.300" 0.040 - Swage Mount 0.094" 1/16 0.067 Brass Electro-Tin YES
10-226-2-044
10-226-2-044
10-226-2-044
0.465" - - Swage Mount 0.105" 1/16 0.206 Brass Bright Tin YES
09-8849-1-03
09-8849-1-03
09-8849-1-03
0.815" 0.042 - Solder - - 0.044 Brass Gold YES
10-220-3-03
10-220-3-03
10-220-3-03
0.271" - - Swage Mount 0.115" 3/32 0.064 Brass Gold YES
09-0118-2-03
09-0118-2-03
09-0118-2-03
0.184" - - Swage Mount 0.084" 1/16 0.033 Brass Gold YES
09-0301-2-01
09-0301-2-01
09-0301-2-01
0.244" - - Swage Mount 0.087" 1/16 0.063 Brass Silver YES
