Commercial
Non-Insulated
Terminals

Filter
10-423-3-05
10-423-3-05
10-423-3-05
0.378" - - Swage Mount 0.135" 3/32 0.094 Brass Electro Solder NO
10-423-1-05
10-423-1-05
10-423-1-05
0.318" - - Swage Mount 0.075" 1/32 0.094 Brass Electro Solder NO
10-207-1-05
10-207-1-05
10-207-1-05
0.309" - - Swage Mount 0.075" 1/32 0.094 Brass Electro Solder NO
10-207-2-05
10-207-2-05
10-207-2-05
0.339" - - Swage Mount 0.105" 1/16 0.094 Brass Electro Solder NO
10-218-3-05
10-218-3-05
10-218-3-05
0.372" - - Swage Mount 0.135" 3/32 0.094 Brass Electro Solder NO
10-218-4-05
10-218-4-05
10-218-4-05
0.402" - - Swage Mount 0.165" 1/8 0.094 Brass Electro Solder NO
09-0379-1-05
09-0379-1-05
09-0379-1-05
0.800" 0.060 ± 0.010 - Solder - - - Brass Electro Solder NO
09-0246-1-05
09-0246-1-05
09-0246-1-05
0.190" 0.041 (+0.000/-0.002) - - - - - Brass Electro Solder NO
09-8123-2-05
09-8123-2-05
09-8123-2-05
0.410" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Electro Solder NO
09-0128-1-05
09-0128-1-05
09-0128-1-05
0.225" - - Swage Mount 0.100" 1/16 0.055 Brass Electro Solder NO
09-0174-1-05
09-0174-1-05
09-0174-1-05
0.205" - - Press Fit/Solder 0.158" 3/32 0.094 Brass Electro Solder NO
10-802-2-05
10-802-2-05
10-802-2-05
0.302" 0.032 TURRET/PIN Swage Mount 0.084" 1/16 0.067 Brass Electro Solder NO
09-8827-1-05
09-8827-1-05
09-8827-1-05
0.190" 0.024 - Solder 0.040" 1/64 0.028 Brass Electro Solder NO
09-8090-3-05
09-8090-3-05
09-8090-3-05
0.405" 0.020 - Solder 0.135" 3/32 0.024 Brass Electro Solder NO
09-8088-2-05
09-8088-2-05
09-8088-2-05
0.599" 0.061 - Press Fit/Solder 0.100" 1/16 0.094 Brass Electro Solder NO
10-812-6-05
10-812-6-05
10-812-6-05
0.719" - Turret/Turret Swage Mount 0.219" 3/16 0.147 Brass Electro Solder NO
10-812-3-05
10-812-3-05
10-812-3-05
0.625" - Turret/Turret Swage Mount 0.125" 3/32 0.147 Brass Electro Solder NO
10-882-4-05
10-882-4-05
10-882-4-05
0.625" - Turret/Turret Swage Mount 0.165" 1/8 0.147 Brass Electro Solder NO
10-226-3-05
10-226-3-05
10-226-3-05
0.495" - - Swage Mount 0.135" 3/32 0.206 Brass Electro Solder NO
10-101-8-05
10-101-8-05
10-101-8-05
0.374" - - Swage Mount 0.270" 1/4 0.076 Brass Electro Solder NO
