Commercial
Non-Insulated
Terminals

Filter
09-8706-1-01
09-8706-1-01
09-8706-1-01
0.281" 0.050 - Press Fit/Solder 0.075" 1/16 0.086 Brass Silver YES
09-8689-4A-035
09-8689-4A-035
09-8689-4A-035
0.245" 0.020 - Swage Mount 0.134" 3/32 0.043 Brass Gold YES
10-922-3-03
10-922-3-03
10-922-3-03
0.365" 0.045 - Swage Mount 0.125" 3/32 0.064 Brass Gold YES
10-833-1-035
10-833-1-035
10-833-1-035
0.376" 0.050 - Swage Mount 0.063" 1/32 0.064 Brass Gold YES
09-8017-2-01
09-8017-2-01
09-8017-2-01
0.545" 0.020 - Solder 0.100" 1/16 0.024 Brass Silver YES
10-803-4-05
10-803-4-05
10-803-4-05
0.520" 0.040 TURRET/PIN Swage Mount 0.145" 1/8 0.076 Brass Electro Solder NO
10-217-5-05
10-217-5-05
10-217-5-05
0.539" - - Swage Mount 0.195" 5/32 0.116 Brass Electro Solder NO
10-823-1-05
10-823-1-05
10-823-1-05
0.534" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.057" 1/32 0.120 Brass Electro Solder NO
09-7010-1-05
09-7010-1-05
09-7010-1-05
0.202" 0.050 - Swage Mount 0.062" 1/32 0.055 Brass Electro Solder NO
10-831-11-05
10-831-11-05
10-831-11-05
0.235" 0.050 - Swage Mount 0.047" 1/64 0.064 Brass Electro Solder NO
09-8855-1-05
09-8855-1-05
09-8855-1-05
0.331" 0.070 - Swage Mount 0.062" 1/32 0.076 Brass Electro Solder NO
09-8068-1-01
09-8068-1-01
09-8068-1-01
0.361" 0.020 - Swage Mount 0.051" 1/32 0.043 Brass Silver YES
10-209-4-05
10-209-4-05
10-209-4-05
0.391" - - Swage Mount 0.172" 1/8 0.094 Brass Electro Solder NO
10-430-2-044
10-430-2-044
10-430-2-044
0.240" - - Swage Mount 0.084" 1/16 0.064 Brass Bright Tin YES
09-8422-4-044
09-8422-4-044
09-8422-4-044
0.307" - - Swage Mount 0.156" 1/8 0.067 Brass Bright Tin YES
09-8642-1-044
09-8642-1-044
09-8642-1-044
0.171" 0.040 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin YES
10-455-4-044
10-455-4-044
10-455-4-044
0.406" - - Swage Mount 0.156" 1/8 0.076 Brass Bright Tin YES
10-455-3-044
10-455-3-044
10-455-3-044
0.375" - - Swage Mount 0.125" 3/32 0.076 Brass Bright Tin YES
10-882-3-04
10-882-3-04
10-882-3-04
0.595" - Turret/Turret Swage Mount 0.135" 3/32 0.147 Brass Electro-Tin YES
10-823-2-05
10-823-2-05
10-823-2-05
0.564" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.087" 1/16 0.120 Brass Electro Solder NO
