Commercial
Non-Insulated
Terminals

Filter
10-462-1-088
10-462-1-088
10-462-1-088
0.209" - - Swage Mount 0.053" 1/32 0.052 Brass Bright Tin-Lead NO
10-864-2-088
10-864-2-088
10-864-2-088
0.615" 0.040 - Swage Mount 0.094" 1/16 0.094 Brass Bright Tin-Lead NO
10-309-6-04
10-309-6-04
10-309-6-04
0.547" - - Swage Mount 0.230" 3/16 0.116 Brass Electro-Tin YES
10-542-4-05
10-542-4-05
10-542-4-05
0.519" - TURRET/DOUBLE TURRET Swage Mount 0.156" 1/8 0.094 Brass Electro Solder NO
10-542-6-035
10-542-6-035
10-542-6-035
0.582" - TURRET/DOUBLE TURRET Swage Mount 0.219" 3/16 0.094 Brass Gold YES
09-8864-2-088
09-8864-2-088
09-8864-2-088
1.655" 0.040 - Swage Mount 0.085" 1/16 0.043 Brass Bright Tin-Lead NO
09-0282-4-04
09-0282-4-04
09-0282-4-04
0.562" 0.125 - Swage Mount 0.156" 1/8 0.129 Brass Electro-Tin YES
10-130-4-088
10-130-4-088
10-130-4-088
0.278" - - Swage Mount 0.141" 1/8 0.094 Brass Bright Tin-Lead NO
10-130-2-04
10-130-2-04
10-130-2-04
0.231" - - Swage Mount 0.094" 1/16 0.094 Brass Electro-Tin YES
10-130-1-04
10-130-1-04
10-130-1-04
0.199" - - Swage Mount 0.062" 1/32 0.094 Brass Electro-Tin YES
09-0340-1-044
09-0340-1-044
09-0340-1-044
0.312" 0.040 (+0.000/-0.003) - Solder 0.062" 1/64 TO 1/32 0.041 Brass Bright Tin YES
10-216-2-04
10-216-2-04
10-216-2-04
0.342" - - Swage Mount 0.105" 1/16 0.094 Brass Electro-Tin YES
10-823-1-044
10-823-1-044
10-823-1-044
0.534" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.057" 1/32 0.120 Brass Bright Tin YES
09-0151-2-04
09-0151-2-04
09-0151-2-04
0.501" - Double Turret/Double Turret Swage Mount 0.094" 1/16 0.094 Brass Electro-Tin YES
14-946-1-04
14-946-1-04
14-946-1-04
0.213" - - Swage Mount 0.062" 1/32 0.063 LEADED Red Brass Electro-Tin YES
10-305-4-035
10-305-4-035
10-305-4-035
0.360" - - Swage Mount 0.172" 1/8 0.113 Brass Gold YES
09-8794-1-035
09-8794-1-035
09-8794-1-035
0.150" 0.020 - Swage Mount 0.051" 1/32 0.031 Brass Gold YES
10-236-5-035
10-236-5-035
10-236-5-035
0.608" - - Swage Mount 0.188" 5/32 0.116 Brass Gold YES
10-317-3-035
10-317-3-035
10-317-3-035
0.447" - - Swage Mount 0.135" 3/32 0.116 Brass Gold YES
10-823-2-05
10-823-2-05
10-823-2-05
0.564" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.087" 1/16 0.120 Brass Electro Solder NO
