Commercial
Non-Insulated
Terminals

Filter
09-7158-1A-01
09-7158-1A-01
09-7158-1A-01
0.191" 0.025 - RIVET MOUNT 0.048" 1/64 0.0625 Brass Silver YES
09-0183-3-04
09-0183-3-04
09-0183-3-04
0.234" 0.030 - Swage Mount 0.109" 3/32 0.062 Brass Electro-Tin YES
09-0293-1-044
09-0293-1-044
09-0293-1-044
0.340" - - Solder - - - Brass Bright Tin YES
10-205-6-035
10-205-6-035
10-205-6-035
0.590" - - Swage Mount 0.230" 3/16 0.116 Brass Gold YES
09-0344-1-095
09-0344-1-095
09-0344-1-095
0.340" - - Solder - - - Brass Hot Solder Dip NO
09-8251-3-03
09-8251-3-03
09-8251-3-03
0.229" - - Swage Mount 0.125" 3/32 0.076 Brass Gold YES
09-0183-1-03
09-0183-1-03
09-0183-1-03
0.203" 0.030 - Swage Mount 0.078" 1/16 0.062 Brass Gold YES
10-462-2-088
10-462-2-088
10-462-2-088
0.240" - - Swage Mount 0.084" 1/16 0.052 Brass Bright Tin-Lead NO
09-8131-1-01
09-8131-1-01
09-8131-1-01
0.240" 0.032 TURRET/PIN Swage Mount 0.051" 1/32 0.067 Brass Silver YES
09-8131-1-03
09-8131-1-03
09-8131-1-03
0.240" 0.032 TURRET/PIN Swage Mount 0.051" 1/32 0.067 Brass Gold YES
09-7020-3-03
09-7020-3-03
09-7020-3-03
0.257" - - Swage Mount 0.117" 3/32 0.059 Brass Gold YES
09-6006-1-03
09-6006-1-03
09-6006-1-03
0.810" 0.025 SQ. SQUARE-WRAP Pin/Slotted Press Fit/Solder 0.080" 1/16 0.055 Brass Gold YES
14-350-3-088
14-350-3-088
14-350-3-088
0.656" - - Swage Mount 0.135" 3/32 0.196 LEADED Red Brass Bright Tin-Lead NO
14-351-6-04
14-351-6-04
14-351-6-04
0.555" - - Swage Mount 0.230" 3/16 0.196 LEADED Red Brass Electro-Tin YES
14-916-1-03
14-916-1-03
14-916-1-03
0.371" 0.040 - Swage Mount 0.051" 1/32 0.043 LEADED Red Brass Gold YES
09-8838-1-03
09-8838-1-03
09-8838-1-03
0.620" 0.040 - Solder 0.080" 1/8 TO 1/4 0.059 Phosphor Bronze Gold YES
10-502-6-095
10-502-6-095
10-502-6-095
0.475" - TURRET/DOUBLE TURRET Swage Mount 0.207" 3/16 0.076 Brass Hot Solder Dip NO
10-806-1-095
10-806-1-095
10-806-1-095
0.505" - - Swage Mount 0.078" 1/32 0.094 Brass Hot Solder Dip NO
10-522-4-01
10-522-4-01
10-522-4-01
0.634" - Turret/Turret Swage Mount 0.165" 1/8 0.206 Brass Silver YES
10-114-1-044
10-114-1-044
10-114-1-044
0.147" - - Swage Mount 0.053" 1/32 0.043 Brass Bright Tin YES
