Commercial
Non-Insulated
Terminals

Filter
09-8076-1-044
09-8076-1-044
09-8076-1-044
0.751" 0.0405 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin YES
10-824-4-044
10-824-4-044
10-824-4-044
0.696" 0.053 (TAPER) TURRET/TAPER PIN Swage Mount 0.156" 1/8 0.147 Brass Bright Tin YES
09-8075-1-044
09-8075-1-044
09-8075-1-044
0.251" 0.0405 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin YES
10-543-4-04
10-543-4-04
10-543-4-04
0.601" - Double Turret/Double Turret Swage Mount 0.156" 1/8 0.094 Brass Electro-Tin YES
09-6032-1-04
09-6032-1-04
09-6032-1-04
0.691" 0.025 SQ. - Press Fit/Solder 0.163" 3/32 0.052 Brass Electro-Tin YES
10-215-6-095
10-215-6-095
10-215-6-095
0.363" - - Swage Mount 0.209" 3/16 0.063 Brass Hot Solder Dip NO
10-105-11-035
10-105-11-035
10-105-11-035
0.146" - - Swage Mount 0.037" 1/64 0.076 Brass Gold YES
09-8251-2-05
09-8251-2-05
09-8251-2-05
0.202" - - Swage Mount 0.098" 1/16 0.076 Brass Electro Solder NO
09-0152-2-01
09-0152-2-01
09-0152-2-01
0.360" - - Swage Mount 0.090" 1/16 0.055 Brass Silver YES
10-310-5-05
10-310-5-05
10-310-5-05
0.398" - - Swage Mount 0.195" 5/32 0.116 Brass Electro Solder NO
10-882-5-03
10-882-5-03
10-882-5-03
0.655" - Turret/Turret Swage Mount 0.195" 5/32 0.147 Brass Gold YES
10-108-11-05
10-108-11-05
10-108-11-05
0.130" - - Swage Mount 0.037" 1/64 0.067 Brass Electro Solder NO
10-514-3-035
10-514-3-035
10-514-3-035
0.375" - Turret/Turret Swage Mount 0.135" 3/32 0.129 Brass Gold YES
09-8825-1-01
09-8825-1-01
09-8825-1-01
0.488" 0.020 - Solder 0.113" 1/64 TO 3/32 0.035 Brass Silver YES
09-7169-1-01
09-7169-1-01
09-7169-1-01
0.312" 0.0405 - RIVET MOUNT 0.056" 1/32 0.044 Brass Silver YES
10-964-2-04
10-964-2-04
10-964-2-04
0.174" 0.025 - Swage Mount 0.082" 1/16 0.035 Brass Electro-Tin YES
10-820-2-044
10-820-2-044
10-820-2-044
0.278" 0.040 - Swage Mount 0.105" 1/16 0.094 Brass Bright Tin YES
10-511-6-095
10-511-6-095
10-511-6-095
0.902" - Double Turret/Double Turret Swage Mount 0.230" 3/16 0.116 Brass Hot Solder Dip NO
09-8563-1-095
09-8563-1-095
09-8563-1-095
0.282" 0.020 - Solder 0.260" 15/64 0.024 Beryllium Copper Hot Solder Dip NO
10-216-3-01
10-216-3-01
10-216-3-01
0.372" - - Swage Mount 0.135" 3/32 0.094 Brass Silver YES
