Commercial
Non-Insulated
Terminals

Filter
09-0384-3-01
09-0384-3-01
09-0384-3-01
0.275" - - 2-56 - - 2-56 THREAD Brass Silver YES
10-214-6-035
10-214-6-035
10-214-6-035
0.365" - - Swage Mount 0.209" 3/16 0.067 Brass Gold YES
09-0312-1-05
09-0312-1-05
09-0312-1-05
0.170" - - Solder 0.123" 3/32 0.089 Brass Electro Solder NO
10-225-4-01
10-225-4-01
10-225-4-01
0.301" - - Swage Mount 0.147" 1/8 0.067 Brass Silver YES
10-501-4-088
10-501-4-088
10-501-4-088
0.331" - Turret/Turret Swage Mount 0.145" 1/8 0.076 Brass Bright Tin-Lead NO
09-8088-2-088
09-8088-2-088
09-8088-2-088
0.599" 0.061 - Press Fit/Solder 0.100" 1/16 0.094 Brass Bright Tin-Lead NO
09-8765-5-044
09-8765-5-044
09-8765-5-044
0.340" 0.022 (+0.000/-0.002) - Solder 0.180" 1/64 TO 5/32 0.024 Brass Bright Tin YES
10-702-8-044
10-702-8-044
10-702-8-044
0.607" - - 4-40 - - 4-40 THREAD Brass Bright Tin YES
10-704-3-05
10-704-3-05
10-704-3-05
0.250" - - 4-40 - - 4-40 THREAD Brass Electro Solder NO
10-885-1-04
10-885-1-04
10-885-1-04
0.395" 0.030 - - - - - Brass Electro-Tin YES
09-0258-1-035
09-0258-1-035
09-0258-1-035
0.346" (0.040 (+0.000/-0.003))/(0.040) Pin/Pin Solder 0.064" 1/32 0.070 Brass Gold YES
09-8859-1-035
09-8859-1-035
09-8859-1-035
1.810" 0.030 - - - - - Brass Gold YES
10-225-4-04
10-225-4-04
10-225-4-04
0.301" - - Swage Mount 0.147" 1/8 0.067 Brass Electro-Tin YES
10-808-2-095
10-808-2-095
10-808-2-095
0.580" - - Swage Mount 0.109" 1/16 0.094 Brass Hot Solder Dip NO
09-0088-3-088
09-0088-3-088
09-0088-3-088
0.406" - - Swage Mount 0.125" 3/32 0.159 Brass Bright Tin-Lead NO
09-0170-1-03
09-0170-1-03
09-0170-1-03
0.199" - - Swage Mount 0.062" 1/32 0.063 Brass Gold YES
10-514-3-01
10-514-3-01
10-514-3-01
0.375" - Turret/Turret Swage Mount 0.135" 3/32 0.129 Brass Silver YES
10-905-4-044
10-905-4-044
10-905-4-044
0.344" - - Swage Mount 0.156" 1/8 0.0635 Brass Bright Tin YES
09-8422-4-095
09-8422-4-095
09-8422-4-095
0.307" - - Swage Mount 0.156" 1/8 0.067 Brass Hot Solder Dip NO
09-7186-1A-035
09-7186-1A-035
09-7186-1A-035
0.191" - - RIVET MOUNT 0.041" 1/64 0.044 Brass Gold YES
