Commercial
Insulated
Pin Terminals

Filter
1114-75-0117
1114-75-0117
1114-75-0117
0.367" - - Press Fit 1/16 0.158 Brass Silver - - PTFE Violet YES
1175-402-0415
1175-402-0415
1175-402-0415
0.447" - - PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Green YES
1102R-75-0317
1102R-75-0317
1102R-75-0317
0.350" - - Press Fit 1/16 0.172 Brass Gold - - PTFE Violet YES
1175-402-08819
1175-402-08819
1175-402-08819
0.447" - - PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE White NO
1114R-17-04417
1114R-17-04417
1114R-17-04417
0.250" 0.040 - Press Fit 1/64 0.136 Brass Bright Tin - - PTFE Violet YES
1114R-19-0517
1114R-19-0517
1114R-19-0517
0.310" 0.085 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Violet NO
1114R-23-0417
1114R-23-0417
1114R-23-0417
0.367" 0.085 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Violet YES
1114R-64-0417
1114R-64-0417
1114R-64-0417
0.310" - - Press Fit 3/32 0.122 Brass Electro-Tin - - PTFE Violet YES
1106-16-08817
1106-16-08817
1106-16-08817
0.890" - - Press Fit 5/32 0.205 Brass Bright Tin-Lead - - PTFE Violet NO
1114R-64-04417
1114R-64-04417
1114R-64-04417
0.310" - - Press Fit 3/32 0.122 Brass Bright Tin - - PTFE Violet YES
1110-40-08815
1110-40-08815
1110-40-08815
0.675" 0.040 Pin/Pin Press Fit 1/8 0.152 Brass Bright Tin-Lead - - PTFE Green NO
1114R-80-0317
1114R-80-0317
1114R-80-0317
0.380" 0.055 - Press Fit 1/32 0.136 Brass Gold - - PTFE Violet YES
1106-40-0415
1106-40-0415
1106-40-0415
0.633" - - Press Fit 1/8 0.158 Brass Electro-Tin - - PTFE Green YES
1175-432-0418
1175-432-0418
1175-432-0418
0.474" - - PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Gray NO
1102-99-0510
1102-99-0510
1102-99-0510
0.269" - - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Black NO
1102-99-0316
1102-99-0316
1102-99-0316
0.269" - - Press Fit 1/32 0.136 Brass Gold - - PTFE Blue YES
1115-06-08817
1115-06-08817
1115-06-08817
0.367" 0.040 - Press Fit 1/16 0.187 Brass Bright Tin-Lead - - PTFE Violet NO
1106-22-0417
1106-22-0417
1106-22-0417
0.375" - - Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Violet YES
1115-10-08817
1115-10-08817
1115-10-08817
0.375" 0.040 - Press Fit 3/32 0.077 Brass Bright Tin-Lead - - PTFE Violet NO
1169-97-07512
1169-97-07512
1169-97-07512
1.063" - - 4-40 Nut 3/32 0.120 Brass ZINC ZINC Brass DIALLYL PHTHALATE Red YES
