Commercial
Insulated
Pin Terminals

Filter
1100-02-0510
1100-02-0510
1100-02-0510
0.213" 0.040 - Press Fit 3/64 0.086 Brass Electro Solder - - PTFE Black NO
1105-02-0310
1105-02-0310
1105-02-0310
1.687" - Double Turret/Double Turret Press Fit 9/16 0.205 Brass Gold - - PTFE Black YES
1153-02-0410
1153-02-0410
1153-02-0410
0.515" 0.040 Pin/Pin Press Fit 1/16 0.113 Brass Electro-Tin - - PTFE Black YES
1104-53-0415
1104-53-0415
1104-53-0415
0.555" - - Press Fit 1/8 0.158 Brass Electro-Tin - - PTFE Green YES
1110-54-04415
1110-54-04415
1110-54-04415
0.350" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Green YES
1110-93-0114
1110-93-0114
1110-93-0114
0.390" 0.035 Pin/Pin Press Fit 1/16 0.086 Brass Silver - - PTFE Yellow NO
1100-01-04417
1100-01-04417
1100-01-04417
0.185" 0.032 - Press Fit 1/32 0.086 Brass Bright Tin - - PTFE Violet YES
1100-01-04415
1100-01-04415
1100-01-04415
0.185" 0.032 - Press Fit 1/32 0.086 Brass Bright Tin - - PTFE Green YES
1156-01-0411
1156-01-0411
1156-01-0411
0.460" - DOUBLE Turret/Tip Press Fit 1/32 0.086 Brass Electro-Tin - - PTFE Brown NO
1102R-01-04413
1102R-01-04413
1102R-01-04413
0.310" - - Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Orange NO
1119-20-04415
1119-20-04415
1119-20-04415
0.500" 0.040 TURRET/PIN Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Green YES
1103-01-0411
1103-01-0411
1103-01-0411
0.250" - - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Brown NO
1103-01-04419
1103-01-04419
1103-01-04419
0.250" - - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE White YES
1110-93-0115
1110-93-0115
1110-93-0115
0.390" 0.035 Pin/Pin Press Fit 1/16 0.086 Brass Silver - - PTFE Green YES
1131-01-0415
1131-01-0415
1131-01-0415
0.687" 0.040 Pin/Tip Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Green YES
1110-93-04418
1110-93-04418
1110-93-04418
0.390" 0.035 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Gray NO
1152R-01-0110
1152R-01-0110
1152R-01-0110
0.350" 0.040 - Press Fit 1/16 0.136 Brass Silver - - PTFE Black YES
1102R-93-0414
1102R-93-0414
1102R-93-0414
0.415" - - Press Fit 1/8 0.136 Brass Electro-Tin - - PTFE Yellow NO
1102-01-0419
1102-01-0419
1102-01-0419
0.310" - - Press Fit 1/16 0.086 Brass Electro-Tin - - PTFE White YES
1114-73-0315
1114-73-0315
1114-73-0315
0.320" - - Press Fit 1/32 0.136 Brass Gold - - PTFE Green YES
