Commercial
Insulated
Pin Terminals

1102-87-0414
1102-87-0414
1102-87-0414
1.268" - - Press Fit 5/32 0.203 Brass Electro-Tin - - PTFE Yellow NO
1127-87-08819
1127-87-08819
1127-87-08819
0.515" - - 2-56 Nut 1/32 0.094 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE White NO
1127-87-0519
1127-87-0519
1127-87-0519
0.515" - - 2-56 Nut 1/32 0.094 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE White NO
1127-87-0517
1127-87-0517
1127-87-0517
0.515" - - 2-56 Nut 1/32 0.094 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Violet NO
1125-87-0516
1125-87-0516
1125-87-0516
0.461" 0.040 - 2-56 - 2-56 THREAD Brass Electro Solder ZINC Brass PTFE Blue NO
1125-87-04414
1125-87-04414
1125-87-04414
0.461" 0.040 - 2-56 - 2-56 THREAD Brass Bright Tin ZINC Brass PTFE Yellow NO
1102-87-0412
1102-87-0412
1102-87-0412
1.268" - - Press Fit 5/32 0.203 Brass Electro-Tin - - PTFE Red NO
1125-87-04412
1125-87-04412
1125-87-04412
0.461" 0.040 - 2-56 - 2-56 THREAD Brass Bright Tin ZINC Brass PTFE Red NO
1125-87-0412
1125-87-0412
1125-87-0412
0.461" 0.040 - 2-56 - 2-56 THREAD Brass Electro-Tin ZINC Brass PTFE Red NO
1102-86-0311
1102-86-0311
1102-86-0311
0.968" - - Press Fit 5/32 0.203 Brass Gold - - PTFE Brown NO
1125-86-0510
1125-86-0510
1125-86-0510
0.760" - - 6-32 Nut 1/8 0.144 Brass Electro Solder Electro-Tin Brass PTFE Black NO
1125-86-0512
1125-86-0512
1125-86-0512
0.760" - - 6-32 Nut 1/8 0.144 Brass Electro Solder Electro-Tin Brass PTFE Red NO
1102-86-0318
1102-86-0318
1102-86-0318
0.968" - - Press Fit 5/32 0.203 Brass Gold - - PTFE Gray NO
1127-86-0512
1127-86-0512
1127-86-0512
0.844" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Red NO
1127-86-0516
1127-86-0516
1127-86-0516
0.844" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Blue NO
1127-86-0518
1127-86-0518
1127-86-0518
0.844" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Gray NO
1102-86-0411
1102-86-0411
1102-86-0411
0.968" - - Press Fit 5/32 0.203 Brass Electro-Tin - - PTFE Brown NO
1102-86-0412
1102-86-0412
1102-86-0412
0.968" - - Press Fit 5/32 0.203 Brass Electro-Tin - - PTFE Red NO
1102-86-0416
1102-86-0416
1102-86-0416
0.968" - - Press Fit 5/32 0.203 Brass Electro-Tin - - PTFE Blue YES
1102-86-0418
1102-86-0418
1102-86-0418
0.968" - - Press Fit 5/32 0.203 Brass Electro-Tin - - PTFE Gray NO
