Commercial
Insulated
Pin Terminals

Filter
1102-33-04417
1102-33-04417
1102-33-04417
0.493" - - Press Fit 1/8 0.152 Brass Bright Tin - - PTFE Violet YES
1153-33-0112
1153-33-0112
1153-33-0112
0.343" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Silver - - PTFE Red NO
1126-33-08819
1126-33-08819
1126-33-08819
1.172" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin-Lead ZINC Brass PTFE White NO
1126-33-0119
1126-33-0119
1126-33-0119
1.172" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass PTFE White YES
1121-33-0110
1121-33-0110
1121-33-0110
0.350" 0.040 Turret/Tip Press Fit 1/32 0.113 Brass Silver - - PTFE Black YES
1126-33-0118
1126-33-0118
1126-33-0118
1.172" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass PTFE Gray NO
1126-33-0117
1126-33-0117
1126-33-0117
1.172" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass PTFE Violet YES
1126-33-0110
1126-33-0110
1126-33-0110
1.172" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass PTFE Black YES
1153-33-04410
1153-33-04410
1153-33-04410
0.343" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Black YES
1153-33-04419
1153-33-04419
1153-33-04419
0.343" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin - - PTFE White YES
1153-33-04417
1153-33-04417
1153-33-04417
0.343" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Violet YES
1153-33-04412
1153-33-04412
1153-33-04412
0.343" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Red NO
1127-33-04410
1127-33-04410
1127-33-04410
0.969" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Black YES
1127-33-04413
1127-33-04413
1127-33-04413
0.969" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Orange YES
1127-33-04414
1127-33-04414
1127-33-04414
0.969" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Yellow YES
1127-33-04417
1127-33-04417
1127-33-04417
0.969" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Violet YES
1127-33-04418
1127-33-04418
1127-33-04418
0.969" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Gray YES
1111-33-04411
1111-33-04411
1111-33-04411
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.166 Brass Bright Tin - - PTFE Brown NO
1111-33-04413
1111-33-04413
1111-33-04413
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.166 Brass Bright Tin - - PTFE Orange NO
1111-33-04414
1111-33-04414
1111-33-04414
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.166 Brass Bright Tin - - PTFE Yellow NO
