Commercial
Insulated
Pin Terminals

Filter
1100-05-0314
1100-05-0314
1100-05-0314
0.262" 0.040 - Press Fit 3/64 0.086 Brass Gold - - PTFE Yellow NO
1117-18-0515
1117-18-0515
1117-18-0515
0.874" - Double Turret/Double Turret 1/4-28 Nut 1/8 0.257 Brass Electro Solder Nickel Brass PTFE Green NO
1100-47-0514
1100-47-0514
1100-47-0514
0.350" 0.040 - Press Fit 1/16 0.166 Brass Electro Solder - - PTFE Yellow NO
1121R-01-0513
1121R-01-0513
1121R-01-0513
0.350" 0.040 Turret/Tip Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Orange NO
1121R-34-0510
1121R-34-0510
1121R-34-0510
0.600" 0.040 TURRET/PIN Press Fit 5/32 0.205 Brass Electro Solder - - PTFE Black NO
1175-713-0519
1175-713-0519
1175-713-0519
0.611" - DOUBLE Turret/Turret PRESS LOCK 3/32 0.154 (+0.003/-0.001) Brass Electro Solder - - PTFE White NO
1133-11-0413
1133-11-0413
1133-11-0413
1.052" 0.040 DOUBLE TURRET/PIN Press Fit Up to 1/4 0.172 Brass Electro-Tin - - PTFE Orange NO
1100R-50-0415
1100R-50-0415
1100R-50-0415
0.500" 0.040 - Press Fit 1/16 0.158 Brass Electro-Tin - - PTFE Green YES
1111-29-0410
1111-29-0410
1111-29-0410
0.836" 0.050 DOUBLE Turret/Tip Press Fit 1/8 0.158 Brass Electro-Tin - - PTFE Black YES
1175-872-0411
1175-872-0411
1175-872-0411
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Electro-Tin - - PTFE Brown NO
1117-52-0418
1117-52-0418
1117-52-0418
0.700" 0.029 Pin/Pin 4-40 Nut 1/16 0.120 Brass Electro-Tin Nickel Brass PTFE Gray NO
09-2084-1-0115
09-2084-1-0115
09-2084-1-0115
1.074" 0.040 ± 0.010 Pin/Pin Press Fit 1/16 0.086 Brass Silver - - PTFE Green YES
1121-18-04414
1121-18-04414
1121-18-04414
1.115" 0.050 Turret/Tip Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE Yellow NO
1127-05-08818
1127-05-08818
1127-05-08818
0.938" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin-Lead Bright Tin-Lead Brass DIALLYL PHTHALATE Gray NO
1127-04-08811
1127-04-08811
1127-04-08811
0.719" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin-Lead Bright Tin-Lead Brass DIALLYL PHTHALATE Brown NO
1175-701-08811
1175-701-08811
1175-701-08811
0.443" - - PRESS LOCK 1/32 0.154 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Brown NO
1110-61-08810
1110-61-08810
1110-61-08810
0.410" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Black NO
1125-28-0417
1125-28-0417
1125-28-0417
0.615" - - Swage Mount 1/16 0.116 ±0.001 Brass Electro-Tin Electro-Tin Brass PTFE Violet YES
1127-54-0414
1127-54-0414
1127-54-0414
0.719" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Yellow YES
1101R-01-0410
1101R-01-0410
1101R-01-0410
0.328" 0.040 - Press Fit 1/32 0.136 Brass Electro-Tin - - PTFE Black YES
