Commercial
Insulated
Pin Terminals

Filter
1127-33-04413
1127-33-04413
1127-33-04413
0.969" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Orange YES
1127-33-04414
1127-33-04414
1127-33-04414
0.969" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Yellow YES
1127-33-04417
1127-33-04417
1127-33-04417
0.969" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Violet YES
1127-33-04418
1127-33-04418
1127-33-04418
0.969" - - 6-32 Nut Up to 1/4 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Gray YES
1111-33-04411
1111-33-04411
1111-33-04411
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.166 Brass Bright Tin - - PTFE Brown NO
1111-33-04413
1111-33-04413
1111-33-04413
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.166 Brass Bright Tin - - PTFE Orange NO
1111-33-04414
1111-33-04414
1111-33-04414
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.166 Brass Bright Tin - - PTFE Yellow NO
1121-32-0315
1121-32-0315
1121-32-0315
0.250" - Turret/Turret Press Fit 1/32 0.070 Brass Gold - - PTFE Green YES
1111-33-04412
1111-33-04412
1111-33-04412
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.166 Brass Bright Tin - - PTFE Red NO
1121-33-04419
1121-33-04419
1121-33-04419
0.350" 0.040 Turret/Tip Press Fit 1/32 0.113 Brass Bright Tin - - PTFE White YES
1125-33-0117
1125-33-0117
1125-33-0117
0.630" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Silver Electro-Tin Brass PTFE Violet YES
1125-33-0115
1125-33-0115
1125-33-0115
0.630" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Silver Electro-Tin Brass PTFE Green YES
1125-33-0111
1125-33-0111
1125-33-0111
0.630" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Silver Electro-Tin Brass PTFE Brown NO
1121-33-0118
1121-33-0118
1121-33-0118
0.350" 0.040 Turret/Tip Press Fit 1/32 0.113 Brass Silver - - PTFE Gray NO
1121-33-0119
1121-33-0119
1121-33-0119
0.350" 0.040 Turret/Tip Press Fit 1/32 0.113 Brass Silver - - PTFE White YES
1153-33-08819
1153-33-08819
1153-33-08819
0.343" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE White NO
1121-33-08818
1121-33-08818
1121-33-08818
0.350" 0.040 Turret/Tip Press Fit 1/32 0.113 Brass Bright Tin-Lead - - PTFE Gray NO
1102-33-04416
1102-33-04416
1102-33-04416
0.493" - - Press Fit 1/8 0.152 Brass Bright Tin - - PTFE Blue YES
1121-33-04410
1121-33-04410
1121-33-04410
0.350" 0.040 Turret/Tip Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Black YES
1121-33-04411
1121-33-04411
1121-33-04411
0.350" 0.040 Turret/Tip Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Brown NO
