Commercial
Insulated
Pin Terminals

Filter
1111-18-04413
1111-18-04413
1111-18-04413
0.550" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Orange NO
1111-18-04412
1111-18-04412
1111-18-04412
0.550" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Red NO
1111-18-0512
1111-18-0512
1111-18-0512
0.550" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.136 Brass Electro Solder - - PTFE Red NO
1114-18-04412
1114-18-04412
1114-18-04412
0.250" 0.040 - Press Fit 1/32 0.136 Brass Bright Tin - - PTFE Red NO
1121-18-0516
1121-18-0516
1121-18-0516
1.115" 0.050 Turret/Tip Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Blue NO
1100-18-0318
1100-18-0318
1100-18-0318
0.247" 0.040 - Press Fit 1/32 0.136 Brass Gold - - PTFE Gray NO
1121-18-0519
1121-18-0519
1121-18-0519
1.115" 0.050 Turret/Tip Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE White NO
1156-18-0510
1156-18-0510
1156-18-0510
0.828" 0.050 DOUBLE Turret/Tip Press Fit 5/32 0.158 Brass Electro Solder - - PTFE Black NO
1121-18-0416
1121-18-0416
1121-18-0416
1.115" 0.050 Turret/Tip Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Blue YES
1121-18-0415
1121-18-0415
1121-18-0415
1.115" 0.050 Turret/Tip Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Green YES
1121-18-0411
1121-18-0411
1121-18-0411
1.115" 0.050 Turret/Tip Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Brown NO
1100-18-0317
1100-18-0317
1100-18-0317
0.247" 0.040 - Press Fit 1/32 0.136 Brass Gold - - PTFE Violet YES
1100-18-0316
1100-18-0316
1100-18-0316
0.247" 0.040 - Press Fit 1/32 0.136 Brass Gold - - PTFE Blue YES
1100-18-0315
1100-18-0315
1100-18-0315
0.247" 0.040 - Press Fit 1/32 0.136 Brass Gold - - PTFE Green YES
1100-18-0313
1100-18-0313
1100-18-0313
0.247" 0.040 - Press Fit 1/32 0.136 Brass Gold - - PTFE Orange NO
1121-18-0410
1121-18-0410
1121-18-0410
1.115" 0.050 Turret/Tip Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Black YES
1156-18-08814
1156-18-08814
1156-18-08814
0.828" 0.050 DOUBLE Turret/Tip Press Fit 5/32 0.158 Brass Bright Tin-Lead - - PTFE Yellow NO
1111-18-0117
1111-18-0117
1111-18-0117
0.550" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.136 Brass Silver - - PTFE Violet YES
1102-18-08811
1102-18-08811
1102-18-08811
0.500" - - Press Fit Up to 3/16 0.136 Brass Bright Tin-Lead - - PTFE Brown NO
1114-18-04413
1114-18-04413
1114-18-04413
0.250" 0.040 - Press Fit 1/32 0.136 Brass Bright Tin - - PTFE Orange NO
