Commercial
Insulated
Pin Terminals

Filter
09-2094-1-0311
09-2094-1-0311
09-2094-1-0311
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Gold - - PTFE Brown NO
09-2094-1-0315
09-2094-1-0315
09-2094-1-0315
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Gold - - PTFE Green YES
09-2094-1-0317
09-2094-1-0317
09-2094-1-0317
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Gold - - PTFE Violet YES
09-2094-1-0318
09-2094-1-0318
09-2094-1-0318
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Gold - - PTFE Gray NO
09-2117-1-0310
09-2117-1-0310
09-2117-1-0310
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Gold Nickel Brass PTFE Black YES
09-2117-1-0319
09-2117-1-0319
09-2117-1-0319
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Gold Nickel Brass PTFE White YES
09-2117-1-0316
09-2117-1-0316
09-2117-1-0316
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Gold Nickel Brass PTFE Blue YES
09-2117-1-0318
09-2117-1-0318
09-2117-1-0318
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Gold Nickel Brass PTFE Gray NO
09-2095-1-0114
09-2095-1-0114
09-2095-1-0114
0.636" 0.060 ± 0.010 Pin/Pin Press Fit 1/8 0.136 Brass Silver - - PTFE Yellow NO
09-2095-1-0119
09-2095-1-0119
09-2095-1-0119
0.636" 0.060 ± 0.010 Pin/Pin Press Fit 1/8 0.136 Brass Silver - - PTFE White YES
09-2094-1-0116
09-2094-1-0116
09-2094-1-0116
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Silver - - PTFE Blue YES
1127-90-0519
1127-90-0519
1127-90-0519
0.643" - - Swage Mount 1/16 0.082 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE White NO
1127-90-0311
1127-90-0311
1127-90-0311
0.643" - - Swage Mount 1/16 0.082 Brass Gold ZINC Brass DIALLYL PHTHALATE Brown YES
1125-90-08816
1125-90-08816
1125-90-08816
0.760" - - 4-40 Nut 1/8 0.120 Brass Bright Tin-Lead Electro-Tin Brass PTFE Blue NO
1127-90-0310
1127-90-0310
1127-90-0310
0.643" - - Swage Mount 1/16 0.082 Brass Gold ZINC Brass DIALLYL PHTHALATE Black YES
1127-90-04419
1127-90-04419
1127-90-04419
0.643" - - Swage Mount 1/16 0.082 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE White YES
1127-89-04411
1127-89-04411
1127-89-04411
0.484" - - Swage Mount 1/16 0.082 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Brown YES
1127-89-04412
1127-89-04412
1127-89-04412
0.484" - - Swage Mount 1/16 0.082 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Red YES
1125-89-0410
1125-89-0410
1125-89-0410
0.698" - - 4-40 Nut 1/16 0.120 Brass Electro-Tin Electro-Tin Brass PTFE Black YES
1127-89-04413
1127-89-04413
1127-89-04413
0.484" - - Swage Mount 1/16 0.082 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Orange YES
