Commercial
Insulated
Pin Terminals

Filter
1111R-36-08817
1111R-36-08817
1111R-36-08817
0.531" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.172 Brass Bright Tin-Lead - - PTFE Violet NO
1110-36-0413
1110-36-0413
1110-36-0413
0.585" 0.045 Pin/Pin Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Orange NO
1111R-36-08816
1111R-36-08816
1111R-36-08816
0.531" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.172 Brass Bright Tin-Lead - - PTFE Blue NO
1169-36-04415
1169-36-04415
1169-36-04415
0.688" - - 4-40 Nut 1/16 0.120 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Green YES
1111-36-0310
1111-36-0310
1111-36-0310
0.531" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.172 Brass Gold - - PTFE Black YES
1111-36-0515
1111-36-0515
1111-36-0515
0.531" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.172 Brass Electro Solder - - PTFE Green NO
1125-36-0518
1125-36-0518
1125-36-0518
0.912" - - 6-32 Nut Up to 3/16 0.144 Brass Electro Solder Electro-Tin Brass PTFE Gray NO
1100R-36-0315
1100R-36-0315
1100R-36-0315
0.390" 0.040 - Press Fit 3/32 0.136 Brass Gold - - PTFE Green YES
1102-36-0319
1102-36-0319
1102-36-0319
0.706" - - Press Fit Up to 1/4 0.152 Brass Gold - - PTFE White YES
1111-36-0118
1111-36-0118
1111-36-0118
0.531" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.172 Brass Silver - - PTFE Gray NO
1102-36-0317
1102-36-0317
1102-36-0317
0.706" - - Press Fit Up to 1/4 0.152 Brass Gold - - PTFE Violet YES
1100-93-0111
1100-93-0111
1100-93-0111
0.315" 0.030 - Press Fit 1/16 0.086 Brass Silver - - PTFE Brown NO
1111R-36-08815
1111R-36-08815
1111R-36-08815
0.531" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.172 Brass Bright Tin-Lead - - PTFE Green NO
1100R-36-0310
1100R-36-0310
1100R-36-0310
0.390" 0.040 - Press Fit 3/32 0.136 Brass Gold - - PTFE Black YES
1111-36-0412
1111-36-0412
1111-36-0412
0.531" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.172 Brass Electro-Tin - - PTFE Red NO
1111-36-08811
1111-36-08811
1111-36-08811
0.531" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.172 Brass Bright Tin-Lead - - PTFE Brown NO
1102-36-0510
1102-36-0510
1102-36-0510
0.706" - - Press Fit Up to 1/4 0.152 Brass Electro Solder - - PTFE Black NO
1102-36-0511
1102-36-0511
1102-36-0511
0.706" - - Press Fit Up to 1/4 0.152 Brass Electro Solder - - PTFE Brown NO
1111-36-0414
1111-36-0414
1111-36-0414
0.531" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.172 Brass Electro-Tin - - PTFE Yellow NO
1111-36-0416
1111-36-0416
1111-36-0416
0.531" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.172 Brass Electro-Tin - - PTFE Blue YES
