Commercial
Insulated
Pin Terminals

Filter
1152-01-0517
1152-01-0517
1152-01-0517
0.350" 0.040 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Violet NO
1129-01-0514
1129-01-0514
1129-01-0514
1.000" 0.030 TURRET/PIN Press Fit Up to 1/4 0.205 Brass Electro Solder - - PTFE Yellow NO
1122-01-0310
1122-01-0310
1122-01-0310
0.250" - - Press Fit 1/64 0.070 Brass Gold - - PTFE Black YES
1129-01-0411
1129-01-0411
1129-01-0411
1.000" 0.030 TURRET/PIN Press Fit Up to 1/4 0.205 Brass Electro-Tin - - PTFE Brown NO
1102-01-0519
1102-01-0519
1102-01-0519
0.310" - - Press Fit 1/16 0.086 Brass Electro Solder - - PTFE White NO
1156R-01-0518
1156R-01-0518
1156R-01-0518
0.460" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.086 Brass Electro Solder - - PTFE Gray NO
1152-01-0518
1152-01-0518
1152-01-0518
0.350" 0.040 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Gray NO
1116-01-08813
1116-01-08813
1116-01-08813
0.506" - Turret/Tip Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Orange NO
1116-01-08811
1116-01-08811
1116-01-08811
0.506" - Turret/Tip Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Brown NO
1129-01-0517
1129-01-0517
1129-01-0517
1.000" 0.030 TURRET/PIN Press Fit Up to 1/4 0.205 Brass Electro Solder - - PTFE Violet NO
1133-01-0416
1133-01-0416
1133-01-0416
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Blue YES
1133-01-0419
1133-01-0419
1133-01-0419
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE White YES
1102R-96-0314
1102R-96-0314
1102R-96-0314
0.280" - - Press Fit 1/16 0.086 Brass Gold - - PTFE Yellow NO
1156R-01-0519
1156R-01-0519
1156R-01-0519
0.460" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.086 Brass Electro Solder - - PTFE White NO
1160-01-0410
1160-01-0410
1160-01-0410
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Black YES
1102-01-0516
1102-01-0516
1102-01-0516
0.310" - - Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Blue NO
1155-01-04417
1155-01-04417
1155-01-04417
0.427" - - Press Fit Up to 3/16 0.204 Brass Bright Tin - - PTFE Violet YES
1157-01-0419
1157-01-0419
1157-01-0419
0.350" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE White YES
1157-01-0417
1157-01-0417
1157-01-0417
0.350" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Violet YES
1157-01-0415
1157-01-0415
1157-01-0415
0.350" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Green YES
