Commercial
Insulated
Pin Terminals

Filter
1102-50-0319
1102-50-0319
1102-50-0319
0.831" - - Press Fit 5/32 0.152 Brass Gold - - PTFE White YES
1111-50-0318
1111-50-0318
1111-50-0318
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Gold - - PTFE Gray NO
1125-50-0311
1125-50-0311
1125-50-0311
0.788" - - 6-32 Nut 1/16 0.144 Brass Gold Electro-Tin Brass PTFE Brown NO
1125-50-0310
1125-50-0310
1125-50-0310
0.788" - - 6-32 Nut 1/16 0.144 Brass Gold Electro-Tin Brass PTFE Black YES
1125-50-0317
1125-50-0317
1125-50-0317
0.788" - - 6-32 Nut 1/16 0.144 Brass Gold Electro-Tin Brass PTFE Violet YES
1125-50-0318
1125-50-0318
1125-50-0318
0.788" - - 6-32 Nut 1/16 0.144 Brass Gold Electro-Tin Brass PTFE Gray NO
1131R-50-0111
1131R-50-0111
1131R-50-0111
0.562" 0.050 Pin/Tip Press Fit 3/32 0.172 Brass Silver - - PTFE Brown NO
1127-50-0318
1127-50-0318
1127-50-0318
0.813" - - Swage Mount 1/16 0.147 Brass Gold ZINC Brass DIALLYL PHTHALATE Gray YES
1106-50-0315
1106-50-0315
1106-50-0315
0.350" - - Press Fit 1/16 0.091 Brass Gold - - PTFE Green YES
1106-50-0316
1106-50-0316
1106-50-0316
0.350" - - Press Fit 1/16 0.091 Brass Gold - - PTFE Blue YES
1125-50-04410
1125-50-04410
1125-50-04410
0.788" - - 6-32 Nut 1/16 0.144 Brass Bright Tin Electro-Tin Brass PTFE Black YES
1127-50-0317
1127-50-0317
1127-50-0317
0.813" - - Swage Mount 1/16 0.147 Brass Gold ZINC Brass DIALLYL PHTHALATE Violet YES
1131R-50-0314
1131R-50-0314
1131R-50-0314
0.562" 0.050 Pin/Tip Press Fit 3/32 0.172 Brass Gold - - PTFE Yellow NO
1131R-50-0317
1131R-50-0317
1131R-50-0317
0.562" 0.050 Pin/Tip Press Fit 3/32 0.172 Brass Gold - - PTFE Violet YES
1114-50-04416
1114-50-04416
1114-50-04416
0.270" 0.060 - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Blue YES
1111-50-04411
1111-50-04411
1111-50-04411
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Brown NO
1111-50-04413
1111-50-04413
1111-50-04413
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Orange NO
1111-50-04414
1111-50-04414
1111-50-04414
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Yellow NO
1127-50-0119
1127-50-0119
1127-50-0119
0.813" - - Swage Mount 1/16 0.147 Brass Silver ZINC Brass DIALLYL PHTHALATE White YES
1127-50-0314
1127-50-0314
1127-50-0314
0.813" - - Swage Mount 1/16 0.147 Brass Gold ZINC Brass DIALLYL PHTHALATE Yellow YES

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
