Commercial
Insulated
Pin Terminals

Filter
1125-05-0310
1125-05-0310
1125-05-0310
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Gold Electro-Tin Brass PTFE Black YES
1125-35-0511
1125-35-0511
1125-35-0511
0.850" - - 6-32 Nut 1/8 0.144 Brass Electro Solder Electro-Tin Brass PTFE Brown NO
1100-05-0314
1100-05-0314
1100-05-0314
0.262" 0.040 - Press Fit 3/64 0.086 Brass Gold - - PTFE Yellow NO
1178R-07-0417
1178R-07-0417
1178R-07-0417
0.390" 0.040 - PRESS LOCK 1/32 - 5/64 0.125 Brass Electro-Tin - - PTFE Violet YES
1127-07-0418
1127-07-0418
1127-07-0418
0.938" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Gray YES
1127-07-0419
1127-07-0419
1127-07-0419
0.938" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE White YES
1106-07-08815
1106-07-08815
1106-07-08815
0.602" - - Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Green NO
1108-07-04419
1108-07-04419
1108-07-04419
1.187" - Double Turret/Double Turret Press Fit Up to 5/16 0.205 Brass Bright Tin - - PTFE White YES
1106-07-0517
1106-07-0517
1106-07-0517
0.602" - - Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Violet NO
1100R-07-04415
1100R-07-04415
1100R-07-04415
0.350" 0.040 - Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Green YES
1100-07-08819
1100-07-08819
1100-07-08819
0.350" 0.040 - Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE White NO
1121R-07-0411
1121R-07-0411
1121R-07-0411
0.500" 0.040 Turret/Tip Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Brown NO
1121R-07-0110
1121R-07-0110
1121R-07-0110
0.500" 0.040 Turret/Tip Press Fit 3/32 0.136 Brass Silver - - PTFE Black YES
1178R-07-0411
1178R-07-0411
1178R-07-0411
0.390" 0.040 - PRESS LOCK 1/32 - 5/64 0.125 Brass Electro-Tin - - PTFE Brown NO
1100-07-04412
1100-07-04412
1100-07-04412
0.350" 0.040 - Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Red NO
1100-07-08815
1100-07-08815
1100-07-08815
0.350" 0.040 - Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Green NO
1107-07-0413
1107-07-0413
1107-07-0413
0.587" 0.040 Pin/Pin Press Fit 1/8 0.158 Brass Electro-Tin - - PTFE Orange NO
1110-07-0116
1110-07-0116
1110-07-0116
0.355" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Silver - - PTFE Blue YES
1106-07-0516
1106-07-0516
1106-07-0516
0.602" - - Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Blue NO
1106-07-0515
1106-07-0515
1106-07-0515
0.602" - - Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Green NO
