Commercial
Insulated
Pin Terminals

Filter
1125-54-04415
1125-54-04415
1125-54-04415
0.788" - - 4-40 Nut 1/16 0.120 Brass Bright Tin Electro-Tin Brass PTFE Green YES
1115-53-0515
1115-53-0515
1115-53-0515
0.593" - Turret/Turret Press Fit 3/32 0.187 Brass Electro Solder - - PTFE Green NO
1175-702-0412
1175-702-0412
1175-702-0412
0.474" - - PRESS LOCK 1/16 0.154 (+0.003/-0.001) Brass Electro-Tin - - PTFE Red NO
1115-53-0513
1115-53-0513
1115-53-0513
0.593" - Turret/Turret Press Fit 3/32 0.187 Brass Electro Solder - - PTFE Orange NO
1175-842-04413
1175-842-04413
1175-842-04413
0.433" - - PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Bright Tin - - PTFE Orange NO
1102-53-0513
1102-53-0513
1102-53-0513
0.431" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Orange NO
1110-53-0114
1110-53-0114
1110-53-0114
0.437" 0.050 TURRET/PIN Press Fit 3/32 0.172 Brass Silver - - PTFE Yellow NO
1110-53-0113
1110-53-0113
1110-53-0113
0.437" 0.050 TURRET/PIN Press Fit 3/32 0.172 Brass Silver - - PTFE Orange NO
1104-53-0310
1104-53-0310
1104-53-0310
0.555" - - Press Fit 1/8 0.158 Brass Gold - - PTFE Black YES
1106-53-0316
1106-53-0316
1106-53-0316
0.641" - - Press Fit Up to 1/4 0.205 Brass Gold - - PTFE Blue YES
1102-82-0417
1102-82-0417
1102-82-0417
0.934" - - Press Fit 5/32 0.203 Brass Electro-Tin - - PTFE Violet YES
1102-53-0514
1102-53-0514
1102-53-0514
0.431" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Yellow NO
1106-53-0113
1106-53-0113
1106-53-0113
0.641" - - Press Fit Up to 1/4 0.205 Brass Silver - - PTFE Orange NO
1110-53-0511
1110-53-0511
1110-53-0511
0.437" 0.050 TURRET/PIN Press Fit 3/32 0.172 Brass Electro Solder - - PTFE Brown NO
1102-53-08816
1102-53-08816
1102-53-08816
0.431" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Blue NO
1177-53-0416
1177-53-0416
1177-53-0416
0.656" 0.030 Pin/Pin PRESS LOCK 1/32 - 1/16 0.115 Brass Electro-Tin - - PTFE Blue YES
1110-52-0112
1110-52-0112
1110-52-0112
0.560" 0.040 Pin/Pin Press Fit 1/16 0.158 Brass Silver - - PTFE Red NO
1115-52-0515
1115-52-0515
1115-52-0515
0.513" - - Press Fit 3/32 0.187 Brass Electro Solder - - PTFE Green NO
1115-52-0511
1115-52-0511
1115-52-0511
0.513" - - Press Fit 3/32 0.187 Brass Electro Solder - - PTFE Brown NO
1177-58-0410
1177-58-0410
1177-58-0410
0.730" 0.050 Pin/Pin PRESS LOCK 1/32 - 1/16 0.136 Brass Electro-Tin - - PTFE Black YES

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
