Commercial
Insulated
Pin Terminals

Filter
1127-48-08813
1127-48-08813
1127-48-08813
0.875" - - Swage Mount 1/8 0.104 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Orange NO
1125-48-0116
1125-48-0116
1125-48-0116
0.388" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass PTFE Blue YES
1125-48-0117
1125-48-0117
1125-48-0117
0.388" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass PTFE Violet YES
1127-48-0410
1127-48-0410
1127-48-0410
0.875" - - Swage Mount 1/8 0.104 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Black YES
1127-48-0411
1127-48-0411
1127-48-0411
0.875" - - Swage Mount 1/8 0.104 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Brown YES
1110-05-0518
1110-05-0518
1110-05-0518
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Gray NO
1132-01-08817
1132-01-08817
1132-01-08817
0.645" 0.090 - Solder 7/32 0.0935 Brass Bright Tin-Lead - - PTFE Violet NO
1121-06-08819
1121-06-08819
1121-06-08819
0.493" 0.040 Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE White NO
1106-06-08811
1106-06-08811
1106-06-08811
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Brown NO
1123-06-08810
1123-06-08810
1123-06-08810
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Black NO
1123-06-08811
1123-06-08811
1123-06-08811
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Brown NO
1123-06-08813
1123-06-08813
1123-06-08813
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Orange NO
1123-06-08814
1123-06-08814
1123-06-08814
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Yellow NO
1123-06-08818
1123-06-08818
1123-06-08818
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Gray NO
1106-06-08816
1106-06-08816
1106-06-08816
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Blue NO
1106-06-08814
1106-06-08814
1106-06-08814
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Yellow NO
1106-06-08813
1106-06-08813
1106-06-08813
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Orange NO
1106-06-08812
1106-06-08812
1106-06-08812
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Red NO
1106-06-08810
1106-06-08810
1106-06-08810
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Black NO
1103-06-0119
1103-06-0119
1103-06-0119
0.520" - - Press Fit 1/8 0.152 Brass Silver - - PTFE White YES
